4 Models and Parts
Operating and Installation Instructions UL 23
No. Designation Qty.
1
Left side cover 1
2
Baffle plate 1
3
DIN 53085 A2 M5 x 10 serrated hex flange bolt 2
4
Intake pipe 1 (for 10.10/10.20)
5
M4 A4 serrated flange nut 16
6
Closed moisture removal box 1
7
40–60 mm hose clamp 2 (for 10.10/10.20)
8
Sleeve 1 (for 10.10/10.20)
9
Exhaust gas flue box 1
10
Flue extension 1 (for 6.10/10.10)
2 (for 6.20/10.20)
11
Exhaust air bracket 1
12
DN 50 gland grommet 1 (for 6.10/10.10)
2 (for 6.20/10.20)
13
Exhaust duct 1
14
Exhaust duct cover 1
15
M4 x 10 A2 pan head screw 12
16
Heat shield 1
17
Air vent 2 (for 6.20/10.20)
1 (for 6.10/10.10)
18
Fan 2
19
Rear cover 1
20
Right side cover 1
21
DIN 933 M8x40 screw 4
22a
DIN 7982 8 x 25 countersunk bolt
(depending on unit model)
5
22b
M5 x 25 A2 countersunk bolt 5
23
Front cover 1
