Grove Published 04-04-2017, Control # 446-09 5-23
RT770E OPERATOR MANUAL LUBRICATION
5
74A
Boom Tele 1 -
Rear Upper
Wear Pads -
Figure 5-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Thoroughly
coat all
areas the
wear pad
moves on
50 hours or 1
week
• 4points
• 16 places
• Extend
boom,
aligning
grease
fittings with
holes in
side of each
boom
section
• [B] 18.7 m
(61.4 ft)
74 B
Boom Tele 2,
3, & 4 Rear
Upper Wear
Pads
Figure 5-8
EP-MPG
Extreme
Pressure
Multipurpose
Grease
6829003477
Thoroughly
coat all
areas the
wear pad
moves on
50 hours or 1
week
•4 Points
• 16 places
• Extend
boom,
aligning
grease
fittings with
holes in
side of each
boom
section
• [A] 34.2 m
(112.5 ft
NOTE: Lubricate items more frequently than interval indicated in table if environmental conditions and/or operating
conditions necessitate.
CAUTION: Do not apply excessive pressure or force when greasing the wear pad, as this can cause the grease fitting to
separate from the wear pad. Only apply grease until resistance is felt.
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube
Interval
Application
Boom
Operation
Mode and
Length
