Section 2 Installation References
2-9
REMOTE ELECTRICAL CONNECTIONS
WARNING
These diagrams are not intended to show proper
wire routing, wire sizing, disconnects, etc., only
the correct wire connections.
All electrical work, including wire routing and
grounding, must conform to local, state and
national electrical codes.
NOTE: The single circuit condenser should be wired
directly to the ice machine’s electrical panel. The
condenser fan runs only when the ice machine is
operating.
Remote Ice Machine
With Single Circuit Model Condenser
115/1/60 or 208-230/1/60
Remote Ice Machine
With Single Circuit Model Condenser
208-230/3/60 or 380-415/3/50
Remote Ice Machine
With Single Circuit Model Condenser
230/1/50
SV1255
SV1256
SINGLE
CIRCUIT
REMOTE
CONDENSER
GROUND
L
1
N = 115V OR L2 = 208-230V
TO SEPARATE
ICE
L
2
L
1
L
2
F
2
F
1
GROUND
GROUND
L
1
L
2
NOTE:
CONDENSER FAN
MOTOR VOLTAGE
MATCHES ICE MACHINE
SV1199
SINGLE
CIRCUIT
REMOTE
CONDENSER
GROUND
L
1
TO SEPARATE
ICE
L
2
L
1
L
2
F
2
F
1
GROUND
GROUND
L
1
L
2
NOTE:
FAN MOTOR
IS 208-230
L
3
L
3
SINGLE
CIRCUIT
REMOTE
CONDENSER
GROUND
L
1
ICE
L
2
L
1
N
F
2
F
1
GROUND
GROUND
L
1
N
NOTE:
FAN MOTOR IS
220-240 VOLT
TO SEPARATE
FUSE/BREAKER (220-240).
To Next Page
