Section 6 Electrical System
6-17
Wiring Diagrams
The following pages contain electrical wiring diagrams. Be sure you are referring to the correct diagram for the
ice machine which you are servicing.
WARNING
Always disconnect power before working on
electrical circuitry.
WIRING DIAGRAM LEGEND
The following symbols are used on all of the wiring diagrams:
* Internal Compressor Overload
(Some models have external compressor overloads)
** Fan Motor Run Capacitor
(Some models do not incorporate fan motor run capacitor)
TB Terminal Board Connection
(Terminal board numbers are printed on the actual terminal board)
( ) Wire Number Designation
(The number is marked at each end of the wire)
>>
>>>>
>>
Multi-Pin Connection
(Electrical Box Side) >> (Compressor Compartment Side)
