Manitowoc J250 User Manual

Section 2Installation References
2-8
Electrical Wiring Connections
SELF-CONTAINED ELECTRICAL
CONNECTIONS
WARNING
These diagrams are not intended to show proper
wire routing, wire sizing, disconnects, etc., only
the correct wire connections.
All electrical work, including wire routing and
grounding, must conform to local, state and
national electrical codes.
Self Contained Ice Machine
115/1/60 or 208-230/1/60
Self Contained Ice Machine
208-230/3/60
Self Contained Ice Machine
208-240/1/50
GROUND
SV1258
GROUND
L
1
L
1
N = 115V
OR
L2 = 208-230
V
TO SEPARATE
FUSE/ BREAKER
ICE MACHINE
CONNECTIONS
SV1190
L
1
L
1
L
2
L
2
L
3
L
3
GROUND
GROUND
TO SEPARATE
FUSE/ BREAKER
ICE MACHINE
CONNECTIONS
SV1191
L
1
L
1
N
N
GROUND
GROUND
TO SEPARATE
FUSE/BREAKER.
DISCONNECT ALL POLES.
ICE MACHINE
CONNECTIONS
