Section 2 Installation References

2-15

Typical Single Circuit Remote Condenser Installation

SV1184

SINGLE CIRCUIT

REMOTE

CONDENSER

DISCHARGE

LINE

LIQUID

LINE

ELECTRICAL

DISCONNECT

NOTE:

BORE A 2.5” DIAMETER HOLE IN

THE ROOF OR WALL FOR

TUBING.

SEAL WITH TAR OR PITCH.

SLOPE TO PREVENT ENTRANCE

OF MOISTURE

ELECTRICAL

DISCONNECT

ELECTRICAL

SUPPLY

ICE

MACHINE

BIN

LIQUID

REFRIGERANT

LINE

DISCHARGE

REFRIGERANT

LINE

36.00”

DROP
