Manitowoc Koolaire K Series User Manual

14 Part Number 000012545 Rev 02 11/16
Installation Section 2
Water Supply and Drain Line Sizing/Connections
Location Water Temperature Water Pressure Ice Machine Fitting
Tubing Size Up to Ice Machine
Fitting
Ice Making Water
Inlet
35°F (2°C) Min.
90°F (32°C) Max.
20 psi (140 kPa) Min.
80 psi (552 kPa) Max.
3/8" (.95 cm) Female Pipe Thread 3/8" (.95 cm) min. inside
diameter
Ice Making Water
Drain
– – 1/2" (1.27 cm) Female Pipe Thread 1/2" (1.27 cm) min. inside
diameter
Condenser Water
Inlet
90°F (32°C) Max. Standard
20 psi (140 kPa) Min.
150 psi (1034 kPa) Max.
High Pressure Option
20 psi (140 kPa) Min.
350 psi (2410 kPa) Max.
3/8" Female Pipe Thread
Condenser Water
Drain
– – 1/2" (1.27 cm) Female Pipe Thread 1/2" (1.27 cm) min. inside
diameter
Bin Drain
– – 3/4" (1.91 cm) Female Pipe Thread 3/4" (1.91 cm) min. inside
diameter
Large Capacity
Bin Drain
– – 1" (2.54 cm) Male Pipe Thread 1" (2.54 cm) min. inside diameter
WATERCOOLED CONDENSER WATER PRESSURE
Water pressure at the condenser cannot exceed 150 psig
(1034 kPa) with the standard water-regulating valve.
Contact your distributor if your water pressure is greater
than 150 psig (1034 kPa). A special order condenser/water-
regulating valve is available that allows water pressure up
to 350 psig (2413 kPa).
Important
The Commonwealth of Massachusetts requires that
all water-cooled models must be connected only to a
closed loop, cooling tower system.
COOLING TOWER APPLICATIONS WATERCOOLED
MODELS
A water cooling tower installation does not require
modification of the ice machine. The water regulator valve
for the condenser continues to control the refrigeration
discharge pressure.
It is necessary to know the amount of heat rejection and
the pressure drop through the condenser and water valves
(inlet and outlet) when using a cooling tower on an ice
machine.
• Water entering the condenser must not exceed 90°F
(32°C).
• Water flow through the condenser must not exceed 5
gallons (19 liters) per minute.
• Allow for a pressure drop of 7 psi (50 kPa) between the
condenser water inlet and the outlet of the ice machine.
• Water exiting the condenser must not exceed 110°F
(43°C).
