305/70R19.5
DUAL
4540
(2059)
4670
(2118)
4860
(2204)
5070
(2300)
5230
(2372)
5410
(2454)
5675 (H)
(2574) (H)
5770
(2617)
6005 (J)
(2724) (J)
SINGLE
4940
(2241)
5130
(2327)
5340
(2422)
5510
(2499)
5745
(2606)
5945
(2697)
6175 (H)
(2801) (H)
6340
(2876)
6610 (J)
(2998) (J)
255/70R22.5
DUAL
3970
(1801)
4110
(1864)
4275
(1939)
4410
(2000)
4455
(2021)
4610
(2091)
4675 (G)
(2121) (G)
4915
(2229)
5070 (H)
(2300) (H)
SINGLE
4190
(1901)
4370
(1982)
4550
(2064)
4675
(2121)
4895
(2220)
5065
(2297)
5205 (G)
(2361) (G)
5400
(2449)
5510 (H)
(2499) (H)
305/75R22.5
DUAL
5840
(2649)
6025
(2733)
6235
(2828)
6610
(2998)
6640
(3012)
6940 (J)
(3148) (J)
SINGLE
6395
(2901)
6620
(3003)
6850
(3107)
7160
(3248)
7300
(3311)
7610 (J)
(3452) (J)
305/85R22.5
DUAL
5355
(2429)
5550
(2517)
5780
(2622)
6005
(2724)
6215
(2819)
6435
(2919)
6780 (H)
(3075) (H)
SINGLE
5840
(2649)
6100
(2767)
6350
(2880)
6610
(2998)
6830
(3098)
7070
(3207)
7390 (H)
(3352) (H)
NOTE: Values shown in parentheses denote load range and values shown in bold are maximum loads.
TIRES FOR TRUCKS IN NORMAL HIGHWAY SERVICE
(TIRES MOUNTED ON 15° DROP CENTER RIMS)
TIRE SIZE USAGE
TIRE LOAD LIMITS, LBS (kg), AT VARIOUS COLD INFLATION PRESSURES, PSI (kPa)
Radial Ply
65
(448)
70
(483)
75
(517)
80
(552)
85
(586)
90
(621)
95
(655)
100
(690)
105
(724)
110
(758)
115
(793)
120
(827)



























Reference Only
