1300A OPERATOR’S MANUAL MAINTENANCE CHECKLIST
Specifications
Hydraulic System
Requirements:
Boom Lift Up/Down..................................................... 29 GPM (98 LPM), 3600 psi +100/-0 (24.8 MPa +689/-0 kPa)
Boom Telescope Out .................................................. 29 GPM (98 LPM), 2800 psi +100/-0 (19.3 MPa +689/-0 kPa)
Boom Telescope In..................................................... 29 GPM (98 LPM), 2950 psi +100/-0 (20.3 MPa +689/-0 kPa)
Hoist System ............................................................. 34 GPM (129 LPM), 3300 psi +100/-0 (22.75 MPa +689/-0 kPa)
Outrigger .................................................................... 14 GPM (53LPM), 3000 psi +100/-0 (20.68) MPa +689/-0 kPa)
Swing.......................................................................... 12 GPM (53 LPM), 3000 psi +100/-0 (20.68 MPa +689/-0 kPa)
Reservoir Capacity..................................................... 76 gal. (287.6 L) at full mark
System Capacity ........................................................ 125 Gallons (473 L)
Filtration ..................................................................... 10 Micron (Return Filter)
Flow rates listed are at free flow condition (approx. 100 psi / 698 kPa)
Hoist System
Wire cable .................................................................. Standard 325 ft (99 m) of 9/16 in. (14.3 mm) dia. Rotation
Resistant Nominal Breaking Strength - 38,500 lbs. (17,463 kg)
Crane Operating Speeds
Rotation, 360° ............................................................ 30 sec. ±5 sec.
Boom Up, (-10° to 80°) .............................................. 24 sec. ±5 sec.
Boom Down, (80° to -10°) .......................................... 22 sec. ±5 sec.
Boom Extend.............................................................. 48 fpm ±6 fpm (14.6 mpm ±1.8 mpm)
Boom Retract ............................................................. 42 fpm ±6 fpm (12.8 mpm ±1.8 mpm)
Outrigger Beam Extend.............................................. 8 sec ±3 sec.
Outrigger Beam Retract.............................................. 7 sec ±3 sec.
Outrigger Jack Extend................................................ 14 sec ±3 sec.
Outrigger Jack Retract................................................ 13 sec ±3 sec.
NOTE: Crane operating speeds based on engine speed at governed RPM and hydraulic
reservoir temperature at 100°F (37.7°C).
Hoist Performance (with 1 part of line)
Layer
Hoist Pull Hoist Speed BOS Hoist Speed
lbs (kg) fpm (mpm) fpm (mpm)
1 10,200 (4626) 111 (33.8) 206 (62.7)
2 9,200 (4173) 123 (37.4) 228 (69.4)
3 8,400 (3810) 135 (41.1) 251 (76.5)
4 7,700 (3492) 147 (44.8) 273 (83.2)
5 7,100 3220 159 (48.4)
All ratings based on 34 GPM at 3300 psi. (129 LPM at 22.75 MPa)
Burst of Speed maximum pull = 3000 lbs. (1361 kg)
Reference Only

Manitowoc National Crane 1300A Specifications

General

Brand	Manitowoc
Model	National Crane 1300A
Category	Construction Equipment
Language	English
