SET-UP OPERATOR MANUAL NTC55
4-10 Published 9-26-2018 Control # 646-02
1. Extend and set the outriggers.
2. Swing the boom over rear of truck chassis.
3. Deploy the jib as outlined in (Jib Operation, page 4-4).
4. Remove the pin (3) from the mast stowage bracket (4).
5. Swing the mast (1) from the stowed position to the top of
the jib (2).
6. Install pin (3) that was removed from the stowage
bracket (4) to secure the mast to the jib boom.
NOTE: The hoist cable must be routed over the mast
assembly and under the roller on the mast for all
configurations.
7. Install the retaining clip (5) to secure pin to mast.
8. Route hoist cable in groove in sheave wheel and secure
with retaining pin (6).
CAUTION
Do not overload the swingaway or the attachment points
when lowering the boom.
CAUTION
Use caution to avoid pinch points while positioning mast.
