CONTROLS AND OPERATING PROCEDURES OPERATOR MANUAL NTC55
3-6 Published 9-26-2018 Control # 646-02
Cab Outrigger Control Panel
The cab outrigger control panel (Figure 3-3) is located on the
superstructure cab front console panel and is used to control
the outriggers from inside the cab. The control panel
contains a touch pad with control buttons and indicators for
extending and retracting the outrigger beams, for raising and
lowering the outrigger jack cylinders and for raising and
lowering the single front outrigger (SFO) — if equipped. The
station contains a level indicator and an emergency stop
switch. All outrigger functions can be controlled from the cab
control panel.
NOTE: The operator must be in the crane cab seat with left
armrest lowered and crane power switch
(Figure 3-4) ON for the crane cab outrigger
controls to operate.
NOTE: To ensure a true reading always make sure the cab
tilt is completely lowered.
Ground Station Outrigger Control Panel
The ground station control panels are located on the left and
right sides of the carrier decking (Figure 3-1). Each control
station has control switches for extending and retracting the
outrigger beams, for raising and lowering the outrigger jack
cylinders and for raising and lowering the single front
outrigger (SFO) — if equipped. Each station contains a level
indicator and an emergency stop switch.
NOTE: Outrigger beam functions can be controlled only
from the side the ground station control panel is
located.
Item Description Item Description
1 Outrigger Midspan Selector Pin 6 Ground Station Outrigger Controls
2 Outrigger Beam Assy Long 7 Outrigger Extend/Retract Cylinder
3 Outrigger Beam Assy Short 8 Console Panel
4 Level Indicator 9 Emergency Stop Switch
5 Outrigger Jack Cylinder 10 Cab Outrigger Controls Panel
