46 Part Number: 040006847 12/19
ICE CHUTE
The ice chute is positioned over the spray nozzles and
allows the ice to easily fall into the bin. It must be firmly
positioned over the Spray Bar Assembly with the front
edge inside the water trough or the spray nozzles will not
be aligned with the spray holes, and spray water will fall
into bin.
1. Grab protruding spray holes on one end and lift up.
2. Pivot ice chute and remove.
3. To re-install the ice chute, grasp protruding spray
holes and position over the spray bar. Make sure the
rear supports are over Spray Bar Assembly, and front
edge is inside the water trough.
Ice Chute
