Mantis 7920 User Manual

21
Contact us at www.mantis.com
Parts List
Key Qty. Part No. Description T1 1
430069 Upper Handle Throttle Side Assembly
T2
1
430071 Upper Handle Assembly, Left
T3
2
430082 Lower Handle W/Plug
T4
1
430084 Handle Brace Assembly
T7
2
377 Handle Clamp
T8
2
4078 M6 Jam Nut
T9
2
478 Throttle Clip
T10
1
400133 Carry Handle
T11 2
470 Bolt 1/4-20 X 3”
T12
2
400523 Knob, Two Prongs, Female
T13
2
395 Acorn Nut
T14
4
972 1/4-20 Two-Way Lock Nut
T15
2 144-2
1/4-20 X 1.125 Hex Head Cap Screw
T16
2
140 Bolt 1/4-20 X 3/8” Long
T17
1
430058 Mantis Logo Label
T18
2
4079 M6 Internal Lock Washer
T19
1
487MA Engine Label
T20
1
465 Fender Guard
T21A
1
400908 Engine Assembly SV-5C/2 (Model No. 7920)
T21B
1
400904 Engine Assembly SV-5CI/2 (Model No. 7924)
T22*
1
468 Drive Shaft
T23
1
466 Worm Gear Housing
T24
1
436 Gasket
T25
1
437A Gear Housing Cover
Key Qty. Part No. Description T26
4
651 #8 Self Tapping Screw
T27
1
423 Roller Bearing
T28
2
425 Worm Bearing Race
T29
1
424 Worm Thrust Bearing
T30
1
422 Worm Shaft
T31 1
426 Worm Disk
T32 1
428 Retaining Ring
T33
1
429 Worm Gear
T34
1
431 Tine Shaft
T35
2
430 Worm Gear Thrust Washer
T36
2
432 Worm Gear Bearing
T37
2
434 Bearing Seal
T38
2
435 Bearing Seal Retainer
T39
1
438RA Tine Assembly, Right
T40
1
438LA Tine Assembly, Left
T41
2
418-1 Tine Retaining Pin
T42
2
430039 Carriage Bolt 1/4-20 X 2.25”
T43
1
430042 Ground Wire Jumper, 2 Cycle Engine
T44
1
400630 Triangle Warning Label (2 Cycle Engine)
T45
1
458 Roller Bearing
T46
1
400010 Worm Gear Transmission Assembly
T49
1
410158 Kickstand, Stand Assembly (Model No. 7924)
T50
1
410113 Kickstand, Bracket And Hardware (Model No. 7924)
*Also in key T46
430088 Mantis 2-Cycle Tiller Color Cover.indd 21 7/10/14 7:49 AM
