E26
E25
E23
E21
E22
E24
E28
E27
E29
E30
Key Part No. Qty. Description
D1 A160000610 1 Cover, Engine
D2 90023804018 2 Screw - 4X18
D3 9110704008 1 Screw - 4X8
D4 13041611520 1 Bolt - 5X25
D5 90023804018 4 Screw - 4X18
D6 61022311520 1 Case, Clutch
D7 90023806012 1 Screw - 6X12
D8 17501411520 1 Washer, Clutch
D9 17504404630 1 Washer, Clutch
D10 17501004635 1 Drum, Clutch
D11 90080836000 1 Bearing, Ball - 6000
D12 90060000010 1 Washer - 10
D13 17501904630 1 Plate, Clutch
D14 17500007531 1 Clutch Asy
D15 17501805130 2 Spring, Clutch
D16 17500905131 2 Shoe, Clutch
D17 17501605020 1 Hub, Clutch
Key Part No. Qty. Description
E1 SB1087 1 Short Block -- Sb1087 Includes Items 2-17
E2 90016205022 2 Screw - 5X22
E3 A130000550 1 Cylinder
E4 V100000160 1 Gasket, Cylinder Included In Gasket Kit
E5 P021007712 1 Piston Kit Includes Items 6-9
E6 A101000090 1 Ring, Piston
E7 10001311520 1 Pin, Piston
E8 10001504630 2 Ring, Retaining
E9 10001411520 2 Spacer, Piston
E10 A011000390 1 Crankshaft Asy Includes Item 11
E11 V553000060 1 Bearing, Needle - 8
E12 10020411521 1 Crankcase Kit Items 13-17
E13 10021242031 2 Seal, Oil
E14 V622000020 2 Pin, Locating
E15 10024242030 1 Gasket, Crankcase Included In Gasket Kit
E16 9403536201 2 Bearing, Ball - 6201
E17 90016205028 3 Screw - 5X28
E18 ------------------ 1 Gasket, Intake Included In Gasket Kit
E19 ------------------ 1 Shield, Intake Included In Gasket Kit
E20 ------------------ 1 Shield, Exhaust Included In Gasket Kit
E21 9111304020 2 Screw - 4X20
E22 A411000220 1 Coil, Ignition
E23 16202152830 1 Lead - Ignition
E24 15901019830 1 Spark Plug -- BPM-8Y
E24 A425000000 1 Spark Plug -- BPMR-8Y Canada Models
E25 15901103432 1 Terminal, Spark Plug Cap
E26 15901201620 1 Cap, Spark Plug
E27 15611004920 1 Grommet
E28 V475002200 1 Tube, Insulator
E29 A409000150 1 Flywheel
E30 61032502730 1 Key,Woodruff
Engine Cover, Fancase,
Clutch Case & Clutch
Explosion D
Ignition, Engine & Short Block
Explosion E
