Key Qty. Part No. Description T6 1 430051 LOWER HANDLE W/PLUG, RIGHT T1
1
430070
TRIGGER HANDLE ASSEMBLY, 4 CYCLE ENGINE, RIGHT
T2
1
430071
HANDLE ASSEMBLY, LEFT
T7
1 430050 LOWER HANDLE W/PLUG, LEFT
T8
1 430085 HANDLE BRACE ASSEMBLY
T10
1
430023
LOOP HANDLE RIGHT HALF
T11
1 430022 LOOP HANDLE LEFT HALF
T12
1 910502 10-32 x 3/4" FLANGE BOLT
T13
2
478
THROTTLE CLIP
T14
2
430025
FOAM GRIP
T15
1 430049 CARRY HANDLE W/GRIP
T16
2 4049 BOLT 1/4-20 x 3.25"
T18
1 4078 M6 JAM NUT
T19
2
400635
LABEL XP TINE WARNING
T20
1
400312
FENDER GUARD
T21
1
400916
ENGINE ASSEMBLY-35CC HONDA
T22*
1
468
DRIVE SHAFT
T23
1 400301 WORM GEAR HOUSING
T24
1
436
GASKET
T25
1
437A
GEAR HOUSING COVER
T26
4
651
#8 SELF TAPPING SCREW
T27
1 423 ROLLER BEARING
T28
2
425
WORM BEARING RACE
T29
1 424 WORM THRUST BEARING
T30
1
422
WORM SHAFT
T31
1
426
WORM DISK
T32
1
428
RETAINING RING
T33
1
429
WORM GEAR
T34
1
431
TINE SHAFT
T35
2 430 WORM GEAR THRUST WASHER
T36
2
432
WORM GEAR BEARING
Key Qty. Part No. Description T37
2
434
BEARING
T38
2
435
BEARING SEAL RETAINER
T39
1
400328
TINE ASSEMBLY, OUTER RIGHT
T40
1
400327
TINE ASSEMBLY, OUTER LEFT
T41
4
418-1
TINE RETAINING PIN
T42
2
430039
CARRIAGE BOLT 1/4-20 x 2.25"
T43
1
400307
ENGINE FLANGE
T44
1 400631 TRIANGLE WARNING LABEL (4 CYCLY ENGINE)
T45
1 458 ROLLER BEARING
T46
1 430058 MANTIS LOGO LABEL
T47
2
395
ACORN NUT
T48
6
972
1/4-20 TWO-WAY LOCK NUT
T49
4 144-2 1/4-20 x 1.125 HEX HEAD CAP SCREW
T50
2 M9452 BOLT 1/4-20 x 1/2" LONG
T51 T52
1
400302
TRANSMISSION ASSEMBLY
T53
2 400523 KNOB, TWO PRONGS, FEMALE
T54
1 430043 GROUND WIRE JUMPER, 4 CYCLE ENGINE
T55
1 4079 M6 INTERNAL LOCK WASHER
T56
1 400132 BEARING
T57
1 400308 CLUTCH DRUM
T58
4 400529 M6 x 33 MM FLANGE BOLT
T59
1 410158 KICKSTAND, STAND ASSEMBLY
T60
1 430037 KICKSTAND, BRACKET AND HARDWARE
T61
1 400524 RETAINING RING
T62
1 400310 THROTTLE STOP, HONDA GX35
T64
1 400313 DUST CAP FOR GREASE FITTING
T65
1 400300 GREASE FITTING
T66
1 400330 TINE ASSEMBLY, INNER RIGHT
T67
1 400329 TINE ASSEMBLY, INNER LEFT
*Also in key T52
