Manusa Visio C2H - Page 35

DMJOIC201EN - v2
VISIO C2H OPERATOR - INSTALLATION MANUAL
35
11.8
Fig.
i
Introduce bottom cover onto brackets as shown in the
diagram.
Attach onto brackets (rotate 90º) as shown in the diagram.
Fig.
11.7
Fig.
11.8
Fig.
11.7
i
Screw the piece to the lock as shown in the diagram.
Ensure that the actuator is between the two projections as
shown in the diagrams.
DET
11.7.1
Fig.
11.7
Fig.
11.6
DET
11.7.1
Nuts & bolts Nuts & bolts
DIN7380 6x10 DIN6798 M-6
DET
11.7.1
Fig.
11.7
Fig.
11.6
Fig.
11.3.1 Lock attachment piece assembly.
11.3 MANUAL UNLOCK ASEMBLY
11.3.2 Bottom and front cover assembly
