Manusa Visio C2H - Page 36

DMJOIC201EN - v2
VISIO C2H OPERATOR - INSTALLATION MANUAL
36
i
Insert the actuator and securing washer as shown in the
diagrams.
Ensure that the actuator is oriented as shown in the diagram.
DET
11.11.2
Fig.
11.11.1
Fig.
11.11
DET
11.11.2
Fig.
11.11.1
Fig.
11.11
Fig.
11.10
i
Insert the rack set onto the bottom cover as shown in the
diagrams.
Ensure that the bolt rests in the slot and is centred with
respect to the hole in the bottom cover as shown in the
diagram.
DET
11.9.1
Fig.
11.10
Fig.
11.9
DET
11.9.1
DET
11.9.1
Fig.
11.9
11.3.3 Rack set assembly.
11.3.4 Unlocking actuator assembly.
