Marantz AV8003 - Page 110

146
IC81 : HD64F36049HV
pin port I/O use STBY Name
Port Setting
Note
Act. init
59
P90/
SCK3_3
I/O O - DEBUG_X0 - L N.C to Virtual Connector Land
60 P91/RXD_3 I/O O - DEBUG_X1/RxD1 - H N.C to Virtual Connector Land
61 P92/TXD_3 I/O O - DEBUG_X2/TxD1 - H N.C to Virtual Connector Land
62 P93 I/O O - DEBUG_X3 - L N.C to Virtual Connector Land
63 P94 I/O O - DEBUG_X4 - L N.C to Virtual Connector Land
64 P95 I/O O - DEBUG_X5 - L N.C to Virtual Connector Land
65 P96 I/O O - DEBUG_X6 - L N.C to Virtual Connector Land
66 P97 I/O O - DEBUG_X7 - L N.C to Virtual Connector Land
67
P70/
SCK3_2
I/O I - INT_SW - SiI9185 Int pin
68 P71/RXD_2 I/O RXD - DEBUG_RxD0 L H RS232C RxD for Debug
69 P72/TXD_2 I/O TXD - DEBUG_TxD0 L H RS232C TxD for Debug
70 P74/TMRIV I/O I - - - - To GND
71 P75/TMCIV I/O I - - - - To GND
72 P76/TMOV I/O I - - - - To GND
73 P77 I/O I - - - - To GND
74 AVss I AVss - - - - GND
75 PB0/AN0 I I - I_5V_CH1 - - 5V Input of SOURCE1
76 PB1/AN1 I I - I_5V_CH2 - - 5V Input of SOURCE2
77 PB2/AN2 I I - I_5V_CH3 - - 5V Input of SOURCE3
78 PB3/AN3 I I - I_5V_CH4 - - 5V Input of SOURCE4
79 PB4/AN4 I I - I_HPD_CH1 - - HPD Input of SINK1
80 PB5/AN5 I I - I_HPD_CH2 - - HDP Input of SINK2
