Marantz AV8003 - Page 148

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
7.1CH INPUT PWB
(
CUP12077Z
)
7.1 IN BN85 ns
p
ns
p
CORD
15P WIRE ASSY(80MM 2.0MM)
CWB1A015080EN
7.1 IN C121 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN C122 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
71IN
C123
00MDD95471300
CER CAP
PF V JA
7
.
1
IN
C123
ns
p
00MDD95471300
CER
.
CAP
.
470
PF
50
V
JA
CCUS1H471JA
7.1 IN C124 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN C125 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN C126 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN C127 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN C128 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
7.1 IN JK15 90M-YT003720R 90M-YT003720R TERMINAL
GOLD PLATE
CJJ4P047Z
7.1 IN JK16 90M-YT003720R 90M-YT003720R TERMINAL
GOLD PLATE
CJJ4P047Z
7.1 IN R121 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
71IN
R122
nsp
00MNN05101610
CHIP RES
100 OHM 1/10W J
CRJ10DJ101T
7
.
1
IN
R122
nsp
00MNN05101610
CHIP
RES
.
100
OHM
1/10W
J
CRJ10DJ101T
7.1 IN R123 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
7.1 IN R124 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
7.1 IN R125 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
7.1 IN R126 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
7.1 IN R127 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
7.1 IN R128 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
CDR-X PWB
(
CUP12077Z
)
CDR-X C141 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
CDR-X C142 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
p
CDR-X C143 ns
p
00MDD91100300 CER. CAP.
10PF 50V JA
CCUS1H100JA
CDR-X C145 ns
p
00MDD91100300 CER. CAP.
10PF 50V JA
CCUS1H100JA
CDR-X C146 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
CDR-X C147 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
CDR-X C148 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
CDR-X C151 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
CDR-X C152 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
CDR-X C153 ns
p
00MDD91100300 CER. CAP.
10PF 50V JA
CCUS1H100JA
CDR-X C155 ns
p
00MDD91100300 CER. CAP.
10PF 50V JA
CCUS1H100JA
CDR-X C156 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
CDR-X C157 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
CDR-X C158 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
CDR-X CN29 ns
p
ns
p
CONN.
5P STRAIGHT 20017WS-05
CJP05GA19ZY
CDR-X IC13 00MHC10102090 00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
CDR-X JK13 943646000870S 943646000870S TERMINAL
XLR JACK
CJS6S003Z
CDR-X JK14 943646000870S 943646000870S TERMINAL
XLR JACK
CJS6S003Z
CDR-X R141 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R142 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR X
R143
nsp
00MNN05103610
CHIP RES
10K OHM 1/10W J
CRJ10DJ103T
CDR
-
X
R143
nsp
00MNN05103610
CHIP
RES
.
10K
OHM
1/10W
J
CRJ10DJ103T
CDR-X R145 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R146 ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
CDR-X R147 ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
CDR-X R151 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R152 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R153 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R155 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
CDR-X R156 ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
C
DR-X R1
5
7n
sp
00
MNN
05
222
6
1
0
C
HIP RE
S
.
2.2K OHM 1/10W J
CRJ10DJ222T
C
5
sp
00 05 6 0
CS
CDR-X SW12 90M-SS000710R 90M-SS000710R SW
SLIDE SWITCH
KSS2B016Z
COMPONENT PWB
(
CUP12074Z
)
COMP. BK81 ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
COMP. C801 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C802 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C803 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C804 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C805 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C806 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C807 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C808 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C809 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C811 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C812 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
COMP. C813 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
COMP. C814 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
