Marantz AV8003 - Page 151

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
COMP. C990 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C991 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C992 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C993 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP
C994
00MDK96103300
CER CAP
UF V KC
COMP
.
C994
ns
p
00MDK96103300
CER
.
CAP
.
0.01
UF
50
V
KC
CCUS1H103KC
COMP. C995 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C996 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C997 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. C998 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
COMP. C999 ns
p
00MDK96103300 CER. CAP.
0.01UF 50V KC
CCUS1H103KC
COMP. CN33 ns
p
ns
p
CONN.
11P WAFER FFC FCZ100E-11SSK
CJP11GA117ZY
COMP. CN34 ns
p
ns
p
CONN.
7P STRAIGHT 20017WS-07
CJP07GA19ZY
COMP. CN36 ns
p
ns
p
CONN.
2PIN CJP02GA19ZY
CJP02GA19ZY
COMP
CN41
nsp
nsp
CONN
17P WAFER FFC FCZ100E-17SSK
CJP17GA117ZY
COMP
.
CN41
nsp
nsp
CONN
.
17P
WAFER
FFC
FCZ100E-17SSK
CJP17GA117ZY
COMP. IC89 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC90 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC91 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC92 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC93 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC94 00MHC10236090 00MHC10236090 IC
NJM2586AM
HVINJM2586AMTE1
COMP. IC95 00MHC10239090 00MHC10239090 IC
NJM2581M
HVINJM2581MTE1
COMP. IC96 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC97 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC98 90M-HC109830R 90M-HC109830R IC
NJM2584M
HVINJM2584MTE1
COMP. IC99 00MHC10236090 00MHC10236090 IC
NJM2586AM
HVINJM2586AMTE1
COMP. JK91 90M-YT004360R 90M-YT004360R TERMINAL
JACK BOARD GOLD PLATE
CJJ4R046Z
COMP. JK92 90M-YT004360R 90M-YT004360R TERMINAL
JACK BOARD GOLD PLATE
CJJ4R046Z
COMP. JK93 90M-YT004360R 90M-YT004360R TERMINAL
JACK BOARD GOLD PLATE
CJJ4R046Z
COMP. Q851 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q852 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q853 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q854 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q855 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q856 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q857 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q858 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q859 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q860 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q861 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. Q862 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
COMP. R831 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP
R832
nsp
00MNN05471610
CHIP RES
470 OHM 1/10W J
CRJ10DJ471T
COMP
.
R832
nsp
00MNN05471610
CHIP
RES
.
470
OHM
1/10W
J
CRJ10DJ471T
COMP. R851 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R852 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R853 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R854 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R855 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R856 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R857 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R858 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
CO
MP. R
859
n
sp
00
MNN
05
1
0
2
6
1
0
C
HIP RE
S
.
1K OHM 1/10W J
CRJ10DJ102T
CO
859
sp
00 05060
CS
COMP. R860 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R861 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R862 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R863 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R864 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R865 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R866 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R867 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R868 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R869 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R870 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R871 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R872 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R873 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
COMP. R874 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
COMP. R875 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
187
