Marantz AV8003 - Page 153

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
COMP. R969 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R970 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R971 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R972 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP
R973
00MNN05750610
CHIP RES
OHM / W J
COMP
.
R973
ns
p
00MNN05750610
CHIP
RES
.
75
OHM
1
/
10
W
J
CRJ10DJ750T
COMP. R974 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R975 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R976 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R977 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R978 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R979 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R980 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R981 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP
R982
nsp
00MNN05470610
CHIP RES
47 OHM 1/10W J
CRJ10DJ470T
COMP
.
R982
nsp
00MNN05470610
CHIP
RES
.
47
OHM
1/10W
J
CRJ10DJ470T
COMP. R983 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R984 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R985 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R986 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R987 ns
p
00MNN05471610 CHIP RES.
470 OHM 1/10W J
CRJ10DJ471T
COMP. R988 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
COMP. R989 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
COMP. R990 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R991 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
p
COMP. R992 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R993 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
COMP. R994 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
COMP. R995 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R996 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
COMP. R997 ns
p
00MNN05470610 CHIP RES.
47 OHM 1/10W J
CRJ10DJ470T
DSP PWB
(
CUP12075Z
)
DSP BN57 ns
p
ns
p
CORD
7P WIRE ASSY(180MM 2.5MM)
CWB1B007180BM
DSP BN66 ns
p
ns
p
CORD
3P WIRE ASSY(300MM 2.5MM)
CWB1C003300BM
DSP BN67
/
U1B ns
p
ns
p
CORD
2P WIRE ASSY(250MM 2.0MM)
CWB1B002250EN
DSP BN70 ns
p
ns
p
CORD
11P WIRE ASSY(300MM 2.0MM)
CWB1A011300EN
DSP BN74 ns
p
ns
p
CORD
2P WIRE ASSY(550MM 2.0MM)
CWZAV8003BN74
DSP BN75 ns
p
ns
p
CORD
WIRE ASSY
CWZSR8001BN85
DSP BN92
/
U1B ns
p
ns
p
CORD
2P WIRE ASSY(150MM 2.0MM)
CWB1C002150EN
DSP C100 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
DSP C101 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C102 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP C103 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
DSP
C104
nsp
90M OA000230R
ELECT CAP
22UF 25V ROA 25V220MF3#
HCEA1EROA220T
DSP
C104
nsp
90M
-
OA000230R
ELECT
CAP
.
22UF
25V
ROA
-
25V220MF3#
-
HCEA1EROA220T
DSP C105 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP C106 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C107 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
DSP C108 ns
p
00MDK96272300 CER. CAP.
2700PF 50V KC
CCUS1H272KC
DSP C109 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C110 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
DSP C111 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C112 ns
p
00MDK96272300 CER. CAP.
2700PF 50V KC
CCUS1H272KC
D
S
P
C
11
3
n
sp
00
MDD
95
1
5
1
300
C
ER.
C
AP.
150PF 50V JA
CCUS1H151JA
S
C3
sp
00 95 5 300
CC
DSP C114 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C115 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C116 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C117 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP C118 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
DSP C119 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
DSP C120 ns
p
00MOA10505020 ELECT CAP.
1UF 50V
CCEA1HH1R0T
DSP C121 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C122 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C123 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA2-50V101MG3#8
CCEA1HRA101T
DSP C124 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C125 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP C126 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C127 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP C128 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP C129 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
189
