Marantz AV8003 - Page 164

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
DSP RC66 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC67 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC68 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC69 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP
RC70
00MNN05473610
CHIP RES
K OHM / W J
DSP
RC70
ns
p
00MNN05473610
CHIP
RES
.
47
K
OHM
1
/
10
W
J
CRJ10DJ473T
DSP RC71 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC72 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC73 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RC74 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RC75 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
DSP RC76 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC77 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC78 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP
RC79
nsp
00MNN05101610
CHIP RES
100 OHM 1/10W J
CRJ10DJ101T
DSP
RC79
nsp
00MNN05101610
CHIP
RES
.
100
OHM
1/10W
J
CRJ10DJ101T
DSP RC80
/
N1B ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
DSP RC81
/
N1B ns
p
00MNN05683610 CHIP RES.
68K OHM 1/10W J
CRJ10DJ683T
DSP RC81
/
U1B ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RC82
/
N1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
DSP RC83
/
N1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
DSP RC84 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RC85 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC86 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
DSP RC87 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
p
DSP RC88 ns
p
00MNN05472610 CHIP RES.
4.7K OHM 1/10W J
CRJ10DJ472T
DSP RC89 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC91 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC93
/
U1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RC94
/
U1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RC95
/
U1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RC96
/
U1B ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RC97
/
U1B ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC98
/
U1B ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RC99
/
U1B ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
DSP RN10 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN11 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN12 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN13 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN14 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN15 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN16 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN17 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP
RN18
90M BW000390R
90M BW000390R
RES COMPO
ARC 241 100R ARRAY
CRJ104DJ101T
DSP
RN18
90M
-
BW000390R
90M
-
BW000390R
RES
.
COMPO
.
ARC
241
100R
ARRAY
CRJ104DJ101T
DSP RN19 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN20 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN21 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RN22 90M-BW000390R 90M-BW000390R RES. COMPO.
ARC 241 100R ARRAY
CRJ104DJ101T
DSP RO13
/
U1B ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RO14
/
N1B ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RR10 00MNM11800020 00MNM11800020 CHIP RES.
180 OHM 1%
CRJ10DF1800T
DSP RR11 00MNM11800020 00MNM11800020 CHIP RES.
180 OHM 1%
CRJ10DF1800T
D
S
P RR1
3
00
MNM122
000
2
0
00
MNM122
000
2
0
C
HIP RE
S
.
220 OHM 1%
CRJ10DF2200T
S
3
00 000 0
00 000 0
CS
DSP RR14 00MNM1033G020 00MNM1033G020 CHIP RES.
3.3 OHM 1%
CRJ10DF3R30T
DSP RR15 00MNM12200020 00MNM12200020 CHIP RES.
220 OHM 1%
CRJ10DF2200T
DSP RR19 00MNM12200020 00MNM12200020 CHIP RES.
220 OHM 1%
CRJ10DF2200T
DSP RR20 00MNM12200020 00MNM12200020 CHIP RES.
220 OHM 1%
CRJ10DF2200T
DSP RR21 00MNM11800020 00MNM11800020 CHIP RES.
180 OHM 1%
CRJ10DF1800T
DSP RR22 00MNM11800020 00MNM11800020 CHIP RES.
180 OHM 1%
CRJ10DF1800T
DSP RR23 00MNM12200020 00MNM12200020 CHIP RES.
220 OHM 1%
CRJ10DF2200T
DSP RR24 ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
DSP RR25 ns
p
00MNN05183610 CHIP RES.
18K OHM 1/10W J
CRJ10DJ183T
DSP RR26 ns
p
00MNN05222610 CHIP RES.
2.2K OHM 1/10W J
CRJ10DJ222T
DSP RR27 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RR28 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
DSP RR29 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RR30 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP RR32 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP RR34 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
