Marantz AV8003 - Page 179

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
HDMI Q815 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
HDMI Q816 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
HDMI Q817 90M-HT600050R 90M-HT600050R TRS.
KTA2014GR
HVTKTA2014GR
HDMI Q818 90M-HT800110R 90M-HT800110R TRS.
KTC4075GR
HVTKTC4075GR
HDMI
Q819
90M HT600050R
90M HT600050R
TRS
KTA GR
HDMI
Q819
90M
-
HT600050R
90M
-
HT600050R
TRS
.
KTA
2014
GR
HVTKTA2014GR
HDMI Q903 90M-BA001620R 90M-BA001620R CHIP TRS.
KRC103S
CVTKRC103S
HDMI Q904 90M-BA001620R 90M-BA001620R CHIP TRS.
KRC103S
CVTKRC103S
HDMI Q905 90M-BA001620R 90M-BA001620R CHIP TRS.
KRC103S
CVTKRC103S
HDMI R101 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R102 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
HDMI R103 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI R104 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R105 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI
R106
nsp
00MNN05000610
CHIP RES
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI
R106
nsp
00MNN05000610
CHIP
RES
.
0
OHM
1/10W
J
CRJ10DJ0R0T
HDMI R107 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R108 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R109 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R110 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R111 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R112 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
HDMI R113 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI R114 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R115 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
p
HDMI R116 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R117 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R118 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R119 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R120 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R121 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R122 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
HDMI R123 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI R124 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R125 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R126 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R127 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R128 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R129 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R130 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R131 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R132 ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
HDMI R133 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI
R134
nsp
00MNN05473610
CHIP RES
47K OHM 1/10W J
CRJ10DJ473T
HDMI
R134
nsp
00MNN05473610
CHIP
RES
.
47K
OHM
1/10W
J
CRJ10DJ473T
HDMI R135 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R136 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R137 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R138 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R139 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R140 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R141 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R145 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R14
6
n
sp
00
MNN
05
1
0
2
6
1
0
C
HIP RE
S
.
1K OHM 1/10W J
CRJ10DJ102T
6
sp
00 05060
CS
HDMI R153 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R155 ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
HDMI R156 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R158 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R301 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R302 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
HDMI R303 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
HDMI R304 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
HDMI R305 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R306 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R307 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI R308 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
HDMI R310 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
HDMI R312 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
HDMI R313 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
HDMI R314 ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
215
