Marantz AV8003 - Page 186

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
HDMI RN67 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN68 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN69 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN70 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI
RN71
90M BW000400R
90M BW000400R
RES COMPO
OHM X ARRAY
HDMI
RN71
90M
-
BW000400R
90M
-
BW000400R
RES
.
COMPO
.
22
OHM
X
4 2012
ARRAY
CRJ104DJ220T
HDMI RN72 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN73 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN75 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN76 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN77 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN78 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN81 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN82 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI
RN83
90M-BW000400R
90M-BW000400R
RES COMPO
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI
RN83
90M-BW000400R
90M-BW000400R
RES
.
COMPO
.
22
OHM
X4
2012
ARRAY
CRJ104DJ220T
HDMI RN84 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN85 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN86 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN87 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN88 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN89 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN90 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN91 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN92 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN93 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN94 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN95 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI RN96 90M-BW000400R 90M-BW000400R RES. COMPO.
22 OHM X4 2012 ARRAY
CRJ104DJ220T
HDMI X301 90M-JX001430R 90M-JX001430R X'TAL
28.322MHZ HC-49/S
COX28322E180TF
HDMI X601 90M-JX001360R 90M-JX001360R X'TAL
28.636MHZ
COX28636E330TF
HDMI X901 90M-JX001190R 90M-JX001190R X'TAL
20MHZ
HOX20000E220TF
INPUT PWB
(
CUP12077Z
)
INPUT BK11 ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
INPUT BN29 ns
p
ns
p
CORD
5P WIRE ASSY(150MM 2.0MM)
CWB1A005150EN
INPUT BN50 ns
p
ns
p
CORD
9P WIRE ASSY(250MM 2.5MM)
CWB1C009250BM
INPUT BN73 ns
p
ns
p
CORD
3P WIRE ASSY(100MM 2.0MM)
CWB1A003100EN
INPUT BN77 ns
p
ns
p
CORD
3P WIRE ASSY(200MM 2.5MM)
CWB1B003200BM
INPUT BN80 ns
p
ns
p
CORD
13P WIRE ASSY(150MM 2.0MM)
CWB1C013150EN
INPUT BN86 ns
p
ns
p
CORD
3P WIRE ASSY(650MM 2.0MM)
CWZAV8003BN86
INPUT BN87 ns
p
ns
p
CORD
9P WIRE ASSY(450MM 2.0MM)
CWZAV8003BN87
INPUT BN88 ns
p
ns
p
CORD
9P WIRE ASSY(400MM 2.0MM)
CWZAV8003BN88
INPUT BN89 ns
p
ns
p
CORD
5P WIRE ASSY(250MM 2.0MM)
CWB1B005250EN
INPUT
C201
nsp
00MDD95471300
CER CAP
470PF 50V JA
CCUS1H471JA
INPUT
C201
nsp
00MDD95471300
CER
.
CAP
.
470PF
50V
JA
CCUS1H471JA
INPUT C202 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C203 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C204 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C205 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C206 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C207 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C208 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C209 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INP
U
T
C
21
0
n
sp
00
MDD
95
471
300
C
ER.
C
AP.
470PF 50V JA
CCUS1H471JA
U
C0
sp
00 95 300
CC
INPUT C211 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C212 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C213 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C214 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C215 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C216 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C217 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C218 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C219 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C220 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C221 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C222 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C223 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C224 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C225 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
INPUT C226 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
222
