Marantz AV8003 - Page 188

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
INPUT C294 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C295 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C296 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C297 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT
C298
00MDD95101300
CER CAP
PF V JA
INPUT
C298
ns
p
00MDD95101300
CER
.
CAP
.
100
PF
50
V
JA
CCUS1H101JA
INPUT C299 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C300 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C301 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C302 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C303 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C304 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C305 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C306 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT
C307
nsp
00MDD95101300
CER CAP
100PF 50V JA
CCUS1H101JA
INPUT
C307
nsp
00MDD95101300
CER
.
CAP
.
100PF
50V
JA
CCUS1H101JA
INPUT C308 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C309 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C310 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C311 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C312 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C313 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C314 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C315 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C316 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
p
INPUT C317 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C318 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C319 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C320 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C321 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C322 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C323 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C324 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C325 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C326 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C327 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C328 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C329 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C330 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C331 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C332 ns
p
00MDD91100300 CER. CAP.
10PF 50V JA
CCUS1H100JA
INPUT C333 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT C334 ns
p
90M-OA000140R ELECT CAP.
10UF 50V ROA-50V100MF3#-
HCEA1HROA100T
INPUT
C335
nsp
00MOA10605020
ELECT CAP
10 UF M 50V RA2 50V100ME3E#
HCEA1HRA100T
INPUT
C335
nsp
00MOA10605020
ELECT
CAP
.
10
UF
M
50V
RA2
-
50V100ME3E#
HCEA1HRA100T
INPUT C336 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C337 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C338 ns
p
00MOA10605020 ELECT CAP.
10 UF M 50V RA2-50V100ME3E#
HCEA1HRA100T
INPUT C339 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C340 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C341 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
INPUT C342 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
INPUT C343 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
INP
U
T
C3
44 n
sp
00
M
O
A47
60
2
5
2
0
ELE
C
T
C
AP.
47UF 25V
CCEA1EH470T
U
C3
sp
00 O 60 5 0
CC
INPUT C345 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C346 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C347 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C348 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C349 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
INPUT C350 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
INPUT C351 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
INPUT C352 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
INPUT C353 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C354 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
INPUT C355 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C356 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
INPUT C357 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
INPUT C358 ns
p
00MOA22605020 ELECT CAP.
22UF 50V RA2-50V220ME3#8
CCEA1HRA220T
INPUT C359 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
INPUT C360 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
224
