Marantz AV8003 - Page 195

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
INPUT R437 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
INPUT R438 ns
p
00MNN05224610 CHIP RES.
220K OHM 1/10W J
CRJ10DJ224T
INPUT R439 ns
p
00MNN05224610 CHIP RES.
220K OHM 1/10W J
CRJ10DJ224T
INPUT RY21 90M-LY000430R 90M-LY000430R RELAY
RELAY (BA1-5H)
CSL1C003ZU
INPUT
RY22
90M LY000430R
90M LY000430R
RELAY
RELAY (BA H)
INPUT
RY22
90M
-
LY000430R
90M
-
LY000430R
RELAY
RELAY
(BA
1-5
H)
CSL1C003ZU
INPUT RY23 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
INPUT RY24 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
MIC PWB
(
CUP12076Z
)
MIC CN20 ns
p
ns
p
CONN.
5P WAFER 20017WR-05
CJP05GB46ZY
MIC JK82 90M-YT004120R 90M-YT004120R TERMINAL
JACK SILVER HTJ-035-18ABP
HJJ2D003Y
PREOUT BOT PWB
(
CUP12080Z
)
PREOUT B BN48 ns
p
ns
p
CORD
9P WIRE ASSY(120MM 2.0MM)
CWB1A009120EN
PREOUT B BN54 ns
p
ns
p
CORD
2P WIRE ASSY(150MM 2.5MM)
CWB1C002150BM
PREOUT B
C701
nsp
90M-OA000230R
ELECT CAP
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT
B
C701
nsp
90M-OA000230R
ELECT
CAP
.
22UF
25V
ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C702 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C703 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C704 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C705 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C706 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C707 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C708 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B C709 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B C710 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
p
PREOUT B C711 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C712 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C713 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C714 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C715 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C716 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C717 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C718 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B C719 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B C720 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT B C721 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C722 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C723 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C724 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C725 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C726 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C727 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C728 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B
C729
nsp
00MDD95471300
CER CAP
470PF 50V JA
CCUS1H471JA
PREOUT
B
C729
nsp
00MDD95471300
CER
.
CAP
.
470PF
50V
JA
CCUS1H471JA
PREOUT B C730 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT B C731 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C732 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C733 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C734 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C735 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT B C736 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C737 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PRE
OU
T B
C
7
38
n
sp
00
MDD
95
471
300
C
ER.
C
AP.
470PF 50V JA
CCUS1H471JA
OU
C 38
sp
00 95 300
CC
PREOUT B C739 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT B C740 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT B C741 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C742 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C743 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C744 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C745 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT B C746 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C747 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT B C748 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C749 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT B C750 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT B C751 ns
p
90M-OA000570R ELECT CAP.
1000UF 10V
CCEA1AH102E
PREOUT B C752 ns
p
00MOA22701620 ELECT CAP.
220UF 16V
CCEA1CH221T
PREOUT B C753 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
PREOUT B C754 ns
p
90M-OA000120R ELECT CAP.
100UF 50V
HCEA1HAHS101T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
231
