Marantz AV8003 - Page 198

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
PREOUT B JK74 943646001450S 943646001450S TERMINAL
E703A0800N XLR OUT
CJS6S004Z
PREOUT B JK75 943646001450S 943646001450S TERMINAL
E703A0800N XLR OUT
CJS6S004Z
PREOUT B Q701 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q702 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B
Q703
90M HT300970R
90M HT300970R
TRS
KTC B
PREOUT
B
Q703
90M
-
HT300970R
90M
-
HT300970R
TRS
.
KTC
2875
B
HVTKTC2875B
PREOUT B Q704 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q705 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT B Q706 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q707 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q708 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q709 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q710 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q711 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B
Q712
90M-HT300970R
90M-HT300970R
TRS
KTC2875B
HVTKTC2875B
PREOUT
B
Q712
90M-HT300970R
90M-HT300970R
TRS
.
KTC2875B
HVTKTC2875B
PREOUT B Q713 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q714 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT B Q715 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q716 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q717 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q718 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q719 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q720 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q721 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q722 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q723 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT B Q724 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q725 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q726 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q727 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT B Q728 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT B Q729 00D2690193901 00D2690193901 CHIP TRS.
KRC104S
CVTKRC104S
PREOUT B Q730 00D2690193901 00D2690193901 CHIP TRS.
KRC104S
CVTKRC104S
PREOUT B Q731 00D2690193901 00D2690193901 CHIP TRS.
KRC104S
CVTKRC104S
PREOUT B Q732 00D2690193901 00D2690193901 CHIP TRS.
KRC104S
CVTKRC104S
PREOUT B Q733 00D2690193901 00D2690193901 CHIP TRS.
KRC104S
CVTKRC104S
PREOUT B Q734 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B Q735 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B Q736 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B Q737 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B Q738 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B Q739 00D2690191903 00D2690191903 CHIP TRS.
KRA104S
HVTKRA104S
PREOUT B
Q740
00D2690193901
00D2690193901
CHIP TRS
KRC104S
CVTKRC104S
PREOUT
B
Q740
00D2690193901
00D2690193901
CHIP
TRS
.
KRC104S
CVTKRC104S
PREOUT B R701 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R702 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R703 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R704 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R705 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R706 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R707 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R708 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PRE
OU
T B R7
09
n
sp
00
MNN
05
1
0
1
6
1
0
C
HIP RE
S
.
100 OHM 1/10W J
CRJ10DJ101T
OU
09
sp
00 05060
CS
PREOUT B R710 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT B R711 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT B R712 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT B R713 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT B R714 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
PREOUT B R715 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R716 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R717 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R718 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R719 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT B R720 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R721 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R722 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R723 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R724 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R725 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
