Marantz AV8003 - Page 200

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
PREOUT B R793 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
PREOUT B R794 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
PREOUT B R795 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
PREOUT B R796 ns
p
00MNN05221610 CHIP RES.
220 OHM 1/10W J
CRJ10DJ221T
PREOUT B
R797
00MNN05330610
CHIP RES
OHM / W J
PREOUT
B
R797
ns
p
00MNN05330610
CHIP
RES
.
33
OHM
1
/
10
W
J
CRJ10DJ330T
PREOUT B R798 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT B R799 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
PREOUT B R800 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
PREOUT B R801 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R802 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R803 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R804 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT B R805 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT B
R807
nsp
00MNN05473610
CHIP RES
47K OHM 1/10W J
CRJ10DJ473T
PREOUT
B
R807
nsp
00MNN05473610
CHIP
RES
.
47K
OHM
1/10W
J
CRJ10DJ473T
PREOUT B R808 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R811 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B R812 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT B RY71 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT B RY72 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT B RY73 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT B RY74 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT B RY75 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT B RY76 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT TOP PWB
(
CUP12080Z
)
PREOUT T C501 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C502 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C503 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C504 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C505 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C506 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C507 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C508 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C509 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C510 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C511 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C512 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C513 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C514 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C515 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C516 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C517 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T
C518
nsp
90M OA000230R
ELECT CAP
22UF 25V ROA 25V220MF3#
HCEA1EROA220T
PREOUT
T
C518
nsp
90M
-
OA000230R
ELECT
CAP
.
22UF
25V
ROA
-
25V220MF3#
-
HCEA1EROA220T
PREOUT T C519 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C520 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C521 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C522 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C523 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C524 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C525 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C526 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PRE
OU
T T
C5
27 n
sp
00
MDD
95
1
0
1
300
C
ER.
C
AP.
100PF 50V JA
CCUS1H101JA
OU
C5
sp
00 95 0 300
CC
PREOUT T C528 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C529 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C530 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C531 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C532 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C533 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C534 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C535 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C536 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
PREOUT T C537 ns
p
00MDD95101300 CER. CAP.
100PF 50V JA
CCUS1H101JA
PREOUT T C538 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C539 ns
p
90M-OA000230R ELECT CAP.
22UF 25V ROA-25V220MF3#-
HCEA1EROA220T
PREOUT T C540 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C541 ns
p
00MDD95471300 CER. CAP.
470PF 50V JA
CCUS1H471JA
PREOUT T C542 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
PREOUT T C543 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
236
