Marantz AV8003 - Page 203

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
PREOUT T Q507 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q508 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q509 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q510 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T
Q511
90M HT300970R
90M HT300970R
TRS
KTC B
PREOUT
T
Q511
90M
-
HT300970R
90M
-
HT300970R
TRS
.
KTC
2875
B
HVTKTC2875B
PREOUT T Q512 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q513 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q514 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q515 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT T Q516 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q517 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q518 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q519 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T
Q520
90M-HT300970R
90M-HT300970R
TRS
KTC2875B
HVTKTC2875B
PREOUT
T
Q520
90M-HT300970R
90M-HT300970R
TRS
.
KTC2875B
HVTKTC2875B
PREOUT T Q521 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q522 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q523 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q524 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT T Q525 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT T Q526 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q527 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q528 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q529 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
PREOUT T Q530 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
PREOUT T R501 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T R502 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R503 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R504 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R505 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R506 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T R507 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T R508 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT T R509 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R510 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R511 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R512 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT T R513 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT T R514 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
PREOUT T R515 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R516 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R517 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T
R518
nsp
00MNN05103610
CHIP RES
10K OHM 1/10W J
CRJ10DJ103T
PREOUT
T
R518
nsp
00MNN05103610
CHIP
RES
.
10K
OHM
1/10W
J
CRJ10DJ103T
PREOUT T R519 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT T R520 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT T R521 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T R522 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R523 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R524 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R525 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R526 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PRE
OU
T T R
5
27 n
sp
00
MNN
05
47
36
1
0
C
HIP RE
S
.
47K OHM 1/10W J
CRJ10DJ473T
OU
5
sp
00 05 36 0
CS
PREOUT T R528 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R529 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R530 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R531 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
PREOUT T R532 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT T R533 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
PREOUT T R534 ns
p
00MNN05105610 CHIP RES.
1M OHM 1/10W J
CRJ10DJ105T
PREOUT T R535 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R536 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R537 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R538 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R539 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT T R540 ns
p
00MNN05100610 CHIP RES.
10 OHM 1/10W J
CRJ10DJ100T
PREOUT T R541 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T R542 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
PREOUT T R543 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
