P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
PREOUT T R615 ns
p
00MNN05473610 CHIP RES.
47K OHM 1/10W J
CRJ10DJ473T
PREOUT T RY51 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY52 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY53 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T
RY54
943682000810S
943682000810S
RELAY
BC H V C P
PREOUT
T
RY54
943682000810S
943682000810S
RELAY
BC
3-12
H
12
V
2
C
2
P
CSL4A016ZU
PREOUT T RY55 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY56 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY57 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY58 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PREOUT T RY59 943682000810S 943682000810S RELAY
BC3-12H 12V 2C2P
CSL4A016ZU
PUSH S/W PWB
(
CUP12076Z
)
PUSH SW C877
/
N1B 90M-DK100800R 90M-DK100800R CER. CAP.
! DKS471ME
KCKDKS471ME
PUSH SW CN88
/
N1B ns
p
ns
p
CONN.
2P WAFER
CJP02GA89ZY
PUSH SW
SW97
/N1B
90M-SP001250R
90M-SP001250R
SW
! JPP1197CSA64
KSH1A001ZV
PUSH
SW
SW97
/N1B
90M-SP001250R
90M-SP001250R
SW
!
JPP1197CSA64
KSH1A001ZV
REGULATOR PWB
(
CUP12078Z
)
REG. BN43 ns
p
ns
p
CORD
9P WIRE ASSY(180MM 2.5MM)
CWB1D009180BM
REG. BN49 ns
p
ns
p
CORD
5P WIRE ASSY(500MM 2.0MM)
CWB1B005500EN
REG. BN53 ns
p
ns
p
CORD
3P WIRE ASSY(400MM 2.5MM )
CWB1C003400BM
REG. C901 ns
p
943134001370S ELECT CAP.
3300UF 35V RA2-35V332MK8#
CCEA1VRA332E
REG. C902 ns
p
943134001370S ELECT CAP.
3300UF 35V RA2-35V332MK8#
CCEA1VRA332E
REG. C903 ns
p
943134001370S ELECT CAP.
3300UF 35V RA2-35V332MK8#
CCEA1VRA332E
REG. C904 00MEA10901670 00MEA10901670 ELECT CAP.
10000UF 16V
CCEA1CH103E
REG. C905 00MEA10901670 00MEA10901670 ELECT CAP.
10000UF 16V
CCEA1CH103E
REG. C906 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
REG. C907 ns
p
00MOA47802520 ELECT CAP.
4700UF 25V
CCEA1EH472E
REG. C908 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C909 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C910 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
REG. C911 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C912 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C913 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C914 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA2-50V101MG3#8
CCEA1HRA101T
REG. C915 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C916 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C917 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C918 ns
p
00MOA10705020 ELECT CAP.
100UF 50V RA2-50V101MG3#8
CCEA1HRA101T
REG. C919 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
REG. C920 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C921 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C922 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
REG. C923 ns
p
00MOA10710020 ELECT CAP.
100UF 100V
CCEA2AH101E
REG
C924
nsp
nsp
CER CAP
0 01UF 50V Z
CCFT1H103ZF
REG
.
C924
nsp
nsp
CER
.
CAP
.
0
.
01UF
50V
Z
CCFT1H103ZF
REG. C925 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
REG. C926 ns
p
00MOA47605020 ELECT CAP.
47UF 50V
CCEA1HH470T
REG. C927 ns
p
ns
p
CER. CAP.
0.01UF 50V Z
CCFT1H103ZF
REG. C928 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C929 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C930 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C931 ns
p
ns
p
FILM CAP.
0.1UF 50V ZF
CCFT1H104ZF
REG. C932 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
RE
G
.
C933
n
sp
00
M
O
A47
60
2
5
2
0
ELE
C
T
C
AP.
47UF 25V
CCEA1EH470T
G
C933
sp
00 O 60 5 0
CC
REG. C934 ns
p
ns
p
CER. CAP.
1000PF 50V KB
CCKT1H102KB
REG. C935 943133001380S 943133001380S FILM CAP.
0.047UF 100V
CCME2A473JXT
REG. C936 943133001380S 943133001380S FILM CAP.
0.047UF 100V
CCME2A473JXT
REG. CN44 00MYP04000760 00MYP04000760 CONN.
7.92MM(YUNHO)
CJP02KA060ZY
REG. CN45 ns
p
ns
p
CONN.
9P WAFER YMW025-09R
CJP09GA01ZY
REG. CN46 ns
p
ns
p
CONN.
5P WAFER YMW025-05R 00906-0014
CJP05GA01ZY
REG. CN47 ns
p
ns
p
CONN.
3P STRAIGHT YMW025-03R
CJP03GA01ZY
REG. CN50 ns
p
ns
p
CONN.
9P WAFER YMW025-09R
CJP09GA01ZY
REG. CN66 ns
p
ns
p
CONN.
3P STRAIGHT YMW025-03R
CJP03GA01ZY
REG. D901 90M-HE200390R 90M-HE200390R DIODE
! GBJ1006
HVDGBJ1006
REG. D902 90M-HE200390R 90M-HE200390R DIODE
! GBJ1006
HVDGBJ1006
REG. D903 90M-HD302360R 90M-HD302360R ZENER DIODE
ZJ6.8B 1/2W
CVDZJ6.8BT
REG. D904 90M-HD302400R 90M-HD302400R ZENER DIODE
ZJ30BT
CVDZJ30BT
REG. D905 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
REG. D906 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
REG. D907 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
