Marantz AV8003 - Page 217

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
XM C620
/
U1B ns
p
00MDD95331300 CER. CAP.
330PF 50V JA
CCUS1H331JA
XM C621
/
U1B ns
p
00MDD95331300 CER. CAP.
330PF 50V JA
CCUS1H331JA
XM C622
/
U1B ns
p
00MDD95331300 CER. CAP.
330PF 50V JA
CCUS1H331JA
XM C623
/
U1B ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
XM
C624
/U1B
00MOA10605020
ELECT CAP
UF V
XM
C624
/U1B
ns
p
00MOA10605020
ELECT
CAP
.
10
UF
50
V
CCEA1HH100T
XM C631
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
XM C632
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
XM C633
/
U1B ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
XM C634
/
U1B ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
XM C801
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
XM C803
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
XM C811
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
XM C812
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
XM
C813
/U1B
nsp
00MOA10605020
ELECT CAP
10UF 50V
CCEA1HH100T
XM
C813
/U1B
nsp
00MOA10605020
ELECT
CAP
.
10UF
50V
CCEA1HH100T
XM D611
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
XM D612
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
XM D615
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
XM D616
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
XM F801
/
U1B ns
p
90M-FC900340R FERRITE CORE
HU-1H4516-600JT
HLZ9Z014Z
XM F802
/
U1B ns
p
90M-FC900340R FERRITE CORE
HU-1H4516-600JT
HLZ9Z014Z
XM F803
/
U1B ns
p
90M-FC900460R EMI FILTER
CHIP BEAD NFM21PC474R1C3
CLZ9R007Z
XM F811
/
U1B ns
p
90M-FC900460R EMI FILTER
CHIP BEAD NFM21PC474R1C3
CLZ9R007Z
XM IC51
/
U1B ns
p
90M-HC110100R IC
IC XM V3B XMDTREV3B
CVIXMDTIC
p
XM IC61
/
U1B ns
p
00MHC10025880 IC
CS4392KZZ
HVICS4392KZZ
XM IC62
/
U1B ns
p
00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
XM J501
/
U1B ns
p
00D2051362009 TERMINAL
XM JACK CAM-D96 CAM D96 R41 402
CJJ9L006Z
XM J502
/
U1B ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
XM J503
/
U1B ns
p
ns
p
BRACKET
BRACKET FOR PWB
CMD1A569
XM J511
/
U1B ns
p
ns
p
CONN.
15P WAFER FFC 12511HS-15
CJP15GA115ZY
XM J801
/
U1B ns
p
ns
p
CONN.
2PIN CJP02GA19ZY
CJP02GA19ZY
XM L501
/
U1B ns
p
00MFN21000080 EMI FILTER
DLW21HN121SQ2L
CLZ9R008Z
XM Q613
/
U1B ns
p
90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
XM Q614
/
U1B ns
p
90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
XM Q615
/
U1B ns
p
90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
XM Q616
/
U1B ns
p
90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
XM Q617
/
U1B ns
p
90M-BA001620R CHIP TRS.
KRC103S
CVTKRC103S
XM Q618
/
U1B ns
p
90M-BA001620R CHIP TRS.
KRC103S
CVTKRC103S
XM Q619
/
U1B ns
p
90M-BA001630R CHIP TRS.
KRA103S
HVTKRA103S
XM Q620
/
U1B ns
p
90M-BA001630R CHIP TRS.
KRA103S
HVTKRA103S
XM Q801
/
U1B ns
p
00MHC98520320 IC
PQ20VZ51
CVIPQ20VZ51
XM Q811
/
U1B ns
p
90M-HC300940R IC
LM1117-ADJ
HVILM1117S-ADJ
XM
R501
/U1B
nsp
00MNN05104610
CHIP RES
100K OHM 1/10W J
CRJ10DJ104T
XM
R501
/U1B
nsp
00MNN05104610
CHIP
RES
.
100K
OHM
1/10W
J
CRJ10DJ104T
XM R502
/
U1B ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
XM R503
/
U1B ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
XM R504
/
U1B ns
p
00MNN05104610 CHIP RES.
100K OHM 1/10W J
CRJ10DJ104T
XM R505
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R506
/
U1B ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
XM R507
/
U1B ns
p
00MNN05102610 CHIP RES.
1K OHM 1/10W J
CRJ10DJ102T
XM R508
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R509
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R
5
12
/U
1B n
sp
00
MNN
05
1
006
1
0
C
HIP RE
S
.
10 OHM 1/10W J
CRJ10DJ100T
5
/U
sp
00 05 006 0
CS
XM R513
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R514
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R515
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R516
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R517
/
U1B ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
XM R518
/
U1B ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
XM R519
/
U1B ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
XM R520
/
U1B ns
p
00MNN05220610 CHIP RES.
22 OHM 1/10W J
CRJ10DJ220T
XM R521
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R522
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R523
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
XM R524
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R525
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R526
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R527
/
U1B ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
XM R528
/
U1B ns
p
00MNN05223610 CHIP RES.
22K OHM 1/10W J
CRJ10DJ223T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
253
