Marantz AV8802/U1B - Page 211

SMPS XLR
REF No. Part No. Part Name Remarks Q'ty New Ver
R6516 nsp RD14B2E6R8JT(5) 00D2412393947 1
R6517 nsp RM73B--560JT +1608 00D2472004946 1
R6519 nsp RM73B--103JT +1608 00D2472009983 1
R6520 nsp RM73B--152JT +1608 00D2472007985 1
R6521 00D2442050904 RS14B3A220JNBST(S) 00D2442050904 1
R6522 nsp RM73B--560JT +1608 00D2472004946 1
R6523 nsp RM73B--682JT +1608 00D2472009941 1
R6524 nsp RM73B--562JT +1608 00D2472009925 1
R6525 nsp RM73B--223DT(1608) 00D2472036927 1
R6526 nsp RM73B--105JT +1608 00D2472014965 1
R6527 nsp RM73B--682DT(1608) 00D2472041967 1
R6528 nsp RM73B--470JT +1608 00D2472004920 1
R6532 nsp RM73B--0R0KT +1608 00D2472018903 1
R6533 00D2442051974 RS14B3A102JNBST(S) 00D2442051974 1
R6536 nsp RM73B--682JT +1608 00D2472009941 1
R6537 nsp RM73B--0R0KT +1608 00D2472018903 1
CAPACIITORS GROUP
C0201,0202 133050090557S CQ93P2A104JT(PPF) 133050090557S 2
C0205,0206 13405040500AS CE68W1V103M(LKG1V103MESEZT) 13405040500AS 2
C0209,0210 13405040500AS CE68W1V103M(LKG1V103MESEZT) 13405040500AS 2
C0215,0216 00MOA477025R6 ROA-25V 471M -I6#PE - S13 (470UF 25V) 00MOA477025R6 2
C0221,0222 00MOA477025R6 ROA-25V 471M -I6#PE - S13 (470UF 25V) 00MOA477025R6 2
C0225,0226 00MOF55102581 1000PF 100V FNS 00MOF55102581 2
C0227,0228 00MOA477025R6 ROA-25V 471M -I6#PE - S13 (470UF 25V) 00MOA477025R6 2
C0235,0236 00MOA477025R6 ROA-25V 471M -I6#PE - S13 (470UF 25V) 00MOA477025R6 2
C0241,0242 00MOF55102581 1000PF 100V FNS 00MOF55102581 2
C0253,0254 00MBF68400016 ! 0.68UF/4.7OHM 00MBF68400016 2
C0255 133050090557S CQ93P2A104JT(PPF) 133050090557S 1
C0301-0312 nsp CC73CH1H221JT +1608 00D2570507934 12
C0314 nsp CC73CH1H272JT +1608 00D2570505949 1
C0316 nsp CC73CH1H272JT +1608 00D2570505949 1
C0318 nsp CC73CH1H272JT +1608 00D2570505949 1
C0320 nsp CC73CH1H272JT +1608 00D2570505949 1
C0322 nsp CC73CH1H272JT +1608 00D2570505949 1
C0324 nsp CC73CH1H272JT +1608 00D2570505949 1
C0325-0338 nsp CC73CH1H221JT +1608 00D2570507934 14
C0340 nsp CC73CH1H272JT +1608 00D2570505949 1
C0342 nsp CC73CH1H272JT +1608 00D2570505949 1
C0344 nsp CC73CH1H272JT +1608 00D2570505949 1
C0346 nsp CC73CH1H272JT +1608 00D2570505949 1
C0348 nsp CC73CH1H272JT +1608 00D2570505949 1
C0350 nsp CC73CH1H272JT +1608 00D2570505949 1
C0352 nsp CC73CH1H272JT +1608 00D2570505949 1
C0353,0354 nsp CC73CH1H221JT +1608 00D2570507934 2
C0355 nsp CC73CH1H272JT +1608 00D2570505949 1
C0357,0358 nsp CC73CH1H221JT +1608 00D2570507934 2
C0359 nsp CC73CH1H272JT +1608 00D2570505949 1
C0501,0502 00D2544573981 CE04W1H100MT(RA3) 00D2544573981 2
C0503 nsp CC73CH1H221JT +1608 00D2570507934 1
C0504,0505 00D2544577945 CE04W1C101MT(RA3) 00D2544577945 2
C0506 nsp CC73CH1H221JT +1608 00D2570507934 1
C0507,0508 00D2544573981 CE04W1H100MT(RA3) 00D2544573981 2
C0509,0510 nsp CK73B1E104KT +1608 00D2570516954 2
C6201,6202 133050083511S CQ93M2A104JT(PEF) 133050083511S 2
C6203,6204 13405025220AS CE04D1C222MBPC(KRB) 13405025220AS 2
C6205 133050090557S CQ93P2A104JT(PPF) 133050090557S 1
C6207 13405013540AS CE04W1V102MT(KR3) 13405013540AS 1
C6209 00D2544761735 CE04W1C472MC(SMQ)
00D2544761735 1
C6210 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C6211 13405013540AS CE04W1V102MT(KR3) 13405013540AS 1
C6213 13405018320AS CE04W1C472MC(KR3) 13405018320AS 1
C6214 13405018220AS CE04W1C222MC(KR3) 13405018220AS 1
C6221,6222 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C6227,6228 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C6235,6236 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
! C6501,6502 13905003020AS DE1E3KX102MB4BN01F U, F, K 13905003020AS 2 6
! C6501,6502 13905002920AS
DE1B3KX471KB4BN01
F
This Parts list describes the product with the following serial No.
A
V8802A N1B : ABD15xxxx01791 or late
r
N 13905002920AS 2 6
! C6503 00D2538022707 CK45F2EAC103MC 00D2538022707 1
! C6504,6505 13305016720AS MPXLC104K27515 13305016720AS 2
C6506 13405028320AS CE04W2G151MC(CXW) 13405028320AS 1
C6509 nsp CK73B1E473KT +1608 N, K 00D2570516941 1
C6510 nsp CK73B1E104KT +1608 00D2570516954 1
! C6511,6512 00D2538022707 CK45F2EAC103MC 00D2538022707 2
C6515 13405040350AS CE04W1E470MT(KZH) 13405040350AS 1
C6516 nsp C1608X7R1H104K 00MDK9610430Y 1
C6517 13305015021AS CQ93M3A272J(PHF) 13305015021AS 1
C6519 13405040450AS CE04W1H220MT(KZH) 13405040450AS 1
! C6520 13905002520AS DE1E3KX332MB4BN01F U, F, K 13905002520AS 1 6
! C6520 13905002320AS
DE1E3KX222MB4BN01
F
This Parts list describes the product with the following serial No.
A
V8802A N1B : ABD15xxxx01791 or late
r
N 13905002320AS 1 6
C6524 nsp CK73B0J475KT +1608 00D2570522906 1
C6525-6527 13405028420AS CE04W0J392MC(ZL) 13405028420AS 3
C6528 nsp CK73B0J475KT +1608 00D2570522906 1
C6529 nsp CK73B1E104KT +1608 00D2570516954 1
C6530 nsp CK73B0J475KT +1608 00D2570522906 1
C6532 133050086565S CQ93M2A222JT(PEF) 133050086565S 1
OTHER PARTS GROUP
B0201,0202 nsp GND TERMINAL FOR PCB 00MYL01010241 2
B6501 nsp M3 SCREW TERMINAL(CMD1A834) 44431033900AS 1
B6503 nsp M3 SCREW TERMINAL(CMD1A834) 44431033900AS 1
B6504 nsp GND TERMINAL FOR PCB 00MYL01010241 1
! F0050 00D2061096022 FUSE(218)T2AL250V 00D2061096022 1
! F0070 65205003443AS FUSE(SCT2A) 65205003443AS 1
! F0201,0202 65205003443AS FUSE(SCT2A) 65205003443AS 2
! F0203,0204 65205003444AS FUSE(SCT2.5A) 65205003444AS 2
! F6201 65205003444AS FUSE(SCT2.5A) 65205003444AS 1
! F6202 65205003443AS FUSE(SCT2A) 65205003443AS 1
! F6206 65205003540AS FUSE(SCT250MA) 65205003540AS 1
H0061,0062 nsp FUSE CLIP(TAPE) 00D2020040909 2
K0320-0334 64301021210AS XLR CONNECTOR (XLR-21) 64301021210AS 15
! L6501 11101005000AS L.FILTER-12290(SQE24x24) U, F 11101005000AS 1
! L6501 11101010120AS L.FILTER-07650(SQE24x24) N, K 11101005000AS 1
N0201 nsp B5P-VH 00MYP06010950 1
N0202 nsp B5B-EH 00MYP06010450 1
N0203 nsp B3B-EH 3P 00MYP06003830 1
N0204 nsp B3B-PH-K-S (LF)(SN) 00MYJ06006230 1
N0301 nsp B15B-PH-K-S (LF)(SN) 00MYJ06006350 1
N0302 nsp B16B-PH-K-S (LF)(SN) 00MYJ06006360 1
N0303 nsp B10B-PH-K-S (LF)(SN) 00MYJ06006300 1
N0501 nsp B3B-PH-K-S (LF)(SN) 00MYJ06006230 1
4
