DAC
DAC PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D0601-0603 251310004507S CG0603MLC-12LE 251310004507S 3
U0106 23681012050AS PCM5100PWR 23681012050AS 1
U0109 23681012050AS PCM5100PWR 23681012050AS 1
U0141 236810086505S AK5358BET 236810086505S 1
U0142 00D2631047906 NJM2115M-TE1 +C 00D2631047906 1
U0412 23281004250AS NJM8068G-TE2 23281004250AS 1
U0415 23281004250AS NJM8068G-TE2 23281004250AS 1
U0418 23281004250AS NJM8068G-TE2 23281004250AS 1
U0421 23281004250AS NJM8068G-TE2 23281004250AS 1
U0424 23281004250AS NJM8068G-TE2 23281004250AS 1
U0427 23281004250AS NJM8068G-TE2 23281004250AS 1
U0430 23281004250AS NJM8068G-TE2 23281004250AS 1
U4011 23171011750AS NJM2845DL1-33 23171011750AS 1
U4012-4018 23681050250AS AK4490EQ 23681050250AS 7
RESISTOR GROUP
R0139 nsp RM73B--102JT 00D2473008941 1
R0141 nsp RM73B--330JT +1005 00D2473004987 1
R0144-0146 nsp RM73B--101JT +1608 00D2472005903 3
R0147,0148 nsp RM73B--332JT +1608 00D2472008968 2
R0149 nsp RM73B--101JT +1608 00D2472005903 1
R0150 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R0151,0152 nsp RM73B--683JT +1608 00D2472011984 2
R0153 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R0154,0155 nsp RM73B--474JT +1608 00D2472013982 2
R0157,0158 nsp RM73B--103JT +1005 00D2473010984 2
R0160 nsp RM73B--473JT+1005 00D2473012940 1
R0161 nsp RM73B--102JT 00D2473008941 1
R0163,0164 nsp RM73B--471JT +1608 00D2472006960 2
R0168,0169 nsp RM73B--103JT +1005 00D2473010984 2
R0171 nsp RM73B--473JT+1005 00D2473012940 1
R0172 nsp RM73B--102JT 00D2473008941 1
R0174,0175 nsp RM73B--471JT +1608 00D2472006960 2
R0401 nsp RM73B--393JT +2125 00D2470011928 1
R0428-0431 nsp RM73B--681JT +2125 00D2470007903 4
R0432-0435 nsp RM73B--821JT +2125 00D2470007929 4
R0436,0437 nsp RM73B--152JT +2125 00D2470007987 2
R0438-0440 nsp RM73B--681JT +2125 00D2470007903 3
R0441 nsp RM73B--122JT +2125 00D2470007961 1
R0443,0444 nsp RM73B--152JT +2125 00D2470007987 2
R0446,0447 nsp RM73B--101JT +2125 00D2470005905 2
R0452-0455 nsp RM73B--681JT +2125 00D2470007903 4
R0456-0459 nsp RM73B--821JT +2125 00D2470007929 4
R0460 nsp RM73B--152JT +2125 00D2470007987 1
R0461 nsp RM73B--332JT +2125 00D2470008960 1
R0462,0463 nsp RM73B--681JT +2125 00D2470007903 2
R0464,0465 nsp RM73B--821JT +2125 00D2470007929 2
R0467 nsp RM73B--152JT +2125 00D2470007987 1
R0468 nsp RM73B--332JT +2125 00D2470008960 1
R0469 nsp RM73B--393JT +2125 00D2470011928 1
R0470,0471 nsp RM73B--101JT +2125 00D2470005905 2
R0476-0479 nsp RM73B--681JT +2125 00D2470007903 4
R0480-0483 nsp RM73B--821JT +2125 00D2470007929 4
R0484,0485 nsp RM73B--152JT +2125 00D2470007987 2
R0486-0489 nsp RM73B--681JT +2125 00D2470007903 4
R0491,0492 nsp RM73B--152JT +2125 00D2470007987 2
R0494,0495 nsp RM73B--101JT +2125 00D2470005905 2
R0500,0501 nsp RM73B--681JT +2125 00D2470007903 2
R0504,0505 nsp RM73B--821JT +2125 00D2470007929 2
R0508 nsp RM73B--332JT +2125 00D2470008960 1
R0510,0511 nsp RM73B--821JT +2125 00D2470007929 2
R0514 nsp RM73B--393JT +2125 00D2470011928 1
R0515 nsp RM73B--332JT +2125 00D2470008960 1
R0518 nsp RM73B--101JT +2125 00D2470005905 1
R0520 nsp RM73B--393JT +2125 00D2470011928 1
R0524-0527 nsp RM73B--681JT +2125 00D2470007903 4
R0528-0531 nsp RM73B--821JT +2125 00D2470007929 4
R0532,0533 nsp RM73B--152JT +2125 00D2470007987 2
R0534-0537 nsp RM73B--681JT +2125 00D2470007903 4
R0539 nsp RM73B--152JT +2125 00D2470007987 1
R0541 nsp RM73B--152JT +2125 00D2470007987 1
R0542,0543 nsp RM73B--101JT +2125 00D2470005905 2
R0548-0551 nsp RM73B--681JT +2125 00D2470007903 4
R0552-0555 nsp RM73B--821JT +2125 00D2470007929 4
R0556,0557 nsp RM73B--152JT +2125 00D2470007987 2
R0558-0561 nsp RM73B--681JT +2125 00D2470007903 4
R0563,0564 nsp RM73B--152JT +2125 00D2470007987 2
R0566,0567 nsp RM73B--101JT +2125 00D2470005905 2
R0572-0575 nsp RM73B--681JT +2125 00D2470007903 4
R0576-0579 nsp RM73B--821JT +2125 00D2470007929 4
R0580,0581 nsp RM73B--152JT +2125 00D2470007987 2
R0582-0585 nsp RM73B--681JT +2125 00D2470007903 4
R0587,0588 nsp RM73B--152JT +2125 00D2470007987 2
R0590,0591 nsp RM73B--101JT +2125 00D2470005905 2
R0604 nsp RM73B--222JT +1608 00D2472008926 1
R4011-4013 nsp RM73B--102JT 00D2473008941 3
R4014 nsp RM73B--0R0KT +2125 00D2470018905 1
R4016-4027 nsp RM73B--0R0KT +1608 00D2472018903 12
R4028-4031 nsp RM73B--102JT 00D2473008941 4
R4033-4048 nsp RM73B--0R0KT +1608 00D2472018903 16
R8076-8079 nsp RM73B--103JT +1608 00D2472009983 4
R8123-8136 nsp RM73B--103JT +1608 00D2472009983 14
R8138 nsp RM73B--0R0KT +2125 00D2470018905 1
R8148-8153 nsp RM73B--0R0KT+1005 00D2473001906 6
CAPACIITORS GROUP
C0146 nsp CK73B0J475KT +1608 00D2570522906 1
C0149 nsp CK73B1A225KT 1608 132350029504S 1
C0150,0151 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C0152,0153 nsp CC73CH1H103JT +2125 00D2570041924 2
C0154,0155 nsp CC73CH1H471JT +1608 00D2570508917 2
C0156 nsp CK73B0J475KT +1608 00D2570522906 1
C0157,0158 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C0159,0160 nsp CK73B0J475KT +1608
00D2570522906 2
C0163,0164 nsp CK73B1E104KT +1608 00D2570516954 2
C0165 nsp CK73B1H102KT +1005 00D2575006993 1
C0166 nsp CK73B0J475KT +1608 00D2570522906 1
