Marantz AV8802/U1B - Page 220

DAC NEW
DAC NEW PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D0601 251310004507S CG0603MLC-12LE 251310004507S 1 7
D0602 251310004507S CG0603MLC-12LE 251310004507S 1 7
D0603 251310004507S CG0603MLC-12LE 251310004507S 1 7
U0106 23681012050AS PCM5100PWR 23681012050AS 1 7
U0109 23681012050AS PCM5100PWR 23681012050AS 1 7
U0141 236810086505S AK5358BET 236810086505S 1 7
U0142 00D2631047906 NJM2115M-TE1 +C 00D2631047906 1 7
U0412 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0415 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0418 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0421 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0424 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0427 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U0430 23281004250AS NJM8068G-TE2 23281004250AS 1 7
U4011 23171011750AS NJM2845DL1-33 23171011750AS 1 7
U4012 23681050250AS AK4490EQ 23681050250AS 1 7
U4013 23681050250AS AK4490EQ 23681050250AS 1 7
U4014 23681050250AS AK4490EQ 23681050250AS 1 7
U4015 23681050250AS AK4490EQ 23681050250AS 1 7
U4016 23681050250AS AK4490EQ 23681050250AS 1 7
U4017 23681050250AS AK4490EQ 23681050250AS 1 7
U4018 23681050250AS AK4490EQ 23681050250AS 1 7
U4019 23171011750AS NJM2845DL1-33 23171011750AS 1 7
RESISTOR GROUP
R0139 nsp RM73B--102JT 00D2473008941 1 7
R0141 nsp RM73B--330JT +1005 00D2473004987 1 7
R0144 nsp RM73B--101JT +1608 00D2472005903 1 7
R0145 nsp RM73B--101JT +1608 00D2472005903 1 7
R0146 nsp RM73B--101JT +1608 00D2472005903 1 7
R0147 nsp RM73B--332JT +1608 00D2472008968 1 7
R0148 nsp RM73B--332JT +1608 00D2472008968 1 7
R0149 nsp RM73B--101JT +1608 00D2472005903 1 7
R0150 nsp RM73B--472JT (1608) +1608 00D2472009909 1 7
R0151 nsp RM73B--683JT +1608 00D2472011984 1 7
R0152 nsp RM73B--683JT +1608 00D2472011984 1 7
R0153 nsp RM73B--472JT (1608) +1608 00D2472009909 1 7
R0154 nsp RM73B--474JT +1608 00D2472013982 1 7
R0155 nsp RM73B--474JT +1608 00D2472013982 1 7
R0157 nsp RM73B--103JT +1005 00D2473010984 1 7
R0158 nsp RM73B--103JT +1005 00D2473010984 1 7
R0160 nsp RM73B--473JT+1005 00D2473012940 1 7
R0161 nsp RM73B--102JT 00D2473008941 1 7
R0163 nsp RM73B--471JT +1608 00D2472006960 1 7
R0164 nsp RM73B--471JT +1608 00D2472006960 1 7
R0168 nsp RM73B--103JT +1005 00D2473010984 1 7
R0169 nsp RM73B--103JT +1005 00D2473010984 1 7
R0171 nsp RM73B--473JT+1005 00D2473012940 1 7
R0172 nsp RM73B--102JT 00D2473008941 1 7
R0174 nsp RM73B--471JT +1608 00D2472006960 1 7
R0175 nsp RM73B--471JT +1608 00D2472006960 1 7
R0181 nsp RM73B--0R0KT+1005 00D2473001906 1 7
R0182 nsp RM73B--0R0KT+1005 00D2473001906 1 7
R0183 nsp RM73B--0R0KT+1005 00D2473001906 1 7
R0401 nsp RM73B--393JT +2125 00D2470011928 1 7
R0428 nsp RM73B--681JT +2125 00D2470007903 1 7
R0429 nsp RM73B--681JT +2125 00D2470007903 1 7
R0430 nsp RM73B--681JT +2125 00D2470007903 1 7
R0431 nsp RM73B--681JT +2125 00D2470007903 1 7
R0432 nsp RM73B--821JT +2125 00D2470007929 1 7
R0433 nsp RM73B--821JT +2125 00D2470007929 1 7
R0434 nsp RM73B--821JT +2125 00D2470007929 1 7
R0435 nsp RM73B--821JT +2125 00D2470007929 1 7
R0436 nsp RM73B--152JT +2125 00D2470007987 1 7
R0437 nsp RM73B--152JT +2125 00D2470007987 1 7
R0438 nsp RM73B--681JT +2125 00D2470007903 1 7
R0439 nsp RM73B--681JT +2125 00D2470007903 1 7
R0440 nsp RM73B--681JT +2125 00D2470007903 1 7
R0441 nsp RM73B--681JT +2125 00D2470007903 1 7
R0443 nsp RM73B--152JT +2125 00D2470007987 1 7
R0444 nsp RM73B--152JT +2125 00D2470007987 1 7
R0446 nsp RM73B--101JT +2125 00D2470005905 1 7
R0447 nsp RM73B--101JT +2125 00D2470005905 1 7
R0452 nsp RM73B--681JT +2125 00D2470007903 1 7
R0453 nsp RM73B--681JT +2125 00D2470007903 1 7
R0454 nsp RM73B--681JT +2125 00D2470007903 1 7
R0455 nsp RM73B--681JT +2125 00D2470007903 1 7
R0456 nsp RM73B--821JT +2125 00D2470007929 1 7
R0457 nsp RM73B--821JT +2125 00D2470007929 1 7
R0458 nsp RM73B--821JT +2125 00D2470007929 1 7
R0459 nsp RM73B--821JT +2125 00D2470007929 1 7
R0460 nsp RM73B--152JT +2125 00D2470007987 1 7
R0461 nsp RM73B--332JT +2125 00D2470008960 1 7
R0462 nsp RM73B--681JT +2125 00D2470007903 1 7
R0463 nsp RM73B--681JT +2125 00D2470007903 1 7
R0464 nsp RM73B--821JT +2125 00D2470007929 1 7
R0465 nsp RM73B--821JT +2125 00D2470007929 1 7
R0467 nsp RM73B--152JT +2125 00D2470007987 1 7
R0468 nsp RM73B--332JT +2125 00D2470008960 1 7
R0469 nsp RM73B--393JT +2125 00D2470011928 1 7
R0470 nsp RM73B--101JT +2125 00D2470005905 1 7
R0471 nsp RM73B--101JT +2125 00D2470005905 1 7
R0476 nsp RM73B--681JT +2125 00D2470007903 1 7
R0477 nsp RM73B--681JT +2125 00D2470007903 1 7
R0478 nsp RM73B--681JT +2125 00D2470007903 1 7
R0479 nsp RM73B--681JT +2125 00D2470007903 1 7
R0480 nsp RM73B--821JT +2125 00D2470007929 1 7
R0481 nsp RM73B--821JT +2125 00D2470007929 1 7
R0482 nsp RM73B--821JT +2125 00D2470007929 1 7
R0483 nsp RM73B--821JT +2125 00D2470007929 1 7
R0484 nsp RM73B--152JT +2125 00D2470007987 1 7
R0485 nsp RM73B--152JT +2125
00D2470007987 1 7
R0486 nsp RM73B--681JT +2125 00D2470007903 1 7
R0487 nsp RM73B--681JT +2125 00D2470007903 1 7
R0488 nsp RM73B--681JT +2125 00D2470007903 1 7
R0489 nsp RM73B--681JT +2125 00D2470007903 1 7
