PACKING
PACKING
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
P1 nsp CABINET SHEET 00D5040192106 1
P2 53121041300AM CARTON CASE 53121041300AM 1 *
P3 53361040000AM CUSHION ASSY 53361040000AM 1 *
P4 nsp ENVELOPE (ZIPPER A4_CAUTION) 535510049008S 1
P5 nsp ENVELOPE (ZIPPER A5 HOLE) 53551005900AS 1
P6 35201031600AM INST. MANUAL (U CD-ROM) AV8802 U 35201031600AM 1 *
P6 35201031700AM INST. MANUAL (N-1 CD-ROM) AV8802 N 35201031700AM 1 *
P6 35201035800AM INST.MANUAL(F CD-ROM) AV8802 F 35201035800AM 1 *
P6 35201037600AM INST. MANUAL (U CD-ROM) AV8802A U 35201037600AM 1 * 3
P6 35201037700AM
INST. MANUAL (N CD-ROM)
This part shall be only for the products with the following serial numbers.
A
V8802A N1B : before ABD15161101661
AV8802A N 35201037700AM 1 * 6
P6 35201037720AM
INST. MANUAL (N CD-ROM)
This part shall be only for the products with the following serial numbers.
A
V8802A N1B : ABD15161101661 or late
r
AV8802A N 35201037720AM 1 * 6
P6 35201037800AM INST. MANUAL (K CD-ROM) AV8802A K 35201037800AM 1 * 3
P6 35201037900AM INST. MANUAL (F CD-ROM) AV8802A F 35201037900AM 1 * 3
P7 54111115000AM GETTING STARTED U AV8802 U 54111115000AM 1 *
P7 54111115100AM GETTING STARTED N AV8802 N 54111115100AM 1 *
P7 54111121200AM GETTING STARTED F AV8802 F 54111121200AM 1 *
P7 54111125800AM QUICK START GUIDE (U) AV8802A U 54111125800AM 1 * 3
P7 54111125900AM QUICK START GUIDE (N) AV8802A N 54111125900AM 1 * 3
P7 54111126000AM QUICK START GUIDE (K) AV8802A K 54111126000AM 1 * 3
P7 54111126100AM QUICK START GUIDE (F) AV8802A F 54111126100AM 1 * 3
P8 nsp SAFETY INSTRUCTIONS (U) AV8802 U 54311037220AM 1 *
P8 nsp SAFETY INSTRUCTIONS(N) AV8802 N 54311037010AM 1 *
P8 nsp SAFETY INSTRUCTIONS (JP) AV8802 F 54111093440AD 1 *
P8 nsp SAFETY INSTRUCTIONS (U) AV8802A U 54311037220AM 1 * 3
P8 nsp
SAFETY INSTRUCTIONS(N)
This part shall be only for the products with the following serial numbers.
A
V8802A N1B : before ABD15161101661
AV8802A N 54311043600AM 1 * 6
P8 nsp
SAFETY INSTRUCTIONS(N)
This part shall be only for the products with the following serial numbers.
A
V8802A N1B : ABD15161101661 or late
r
AV8802A N 54311037040AM 1 * 6
P8 nsp SAFETY INSTRUCTIONS (E1C) AV8802A K 54311043300AS 1 * 3
P8 nsp SAFETY INSTRUCTIONS (JP) AV8802A F 54311043400AS 1 * 3
P9 nsp SAFETY INSTRUCTIONS (NOTES ON RADIO) AV8802 54311041500AM 1
P9 nsp SAFETY INSTRUCTIONS (NOTES ON RADIO) AV8802A 54311042700AM 1 * 3
P10 nsp WARRANTY USA U 54311010512AM 1
P11 nsp WARRANTY F (HOSHOUSHO) F 00M27AK854013 1
P12 nsp WARRANTY CANADA U 00M183J854018 1
P13 11601005100AS AM LOOP ANTENNA 11601005100AS 1
P14 11601005200AS FM ANTENNA ASSY 11601005200AS 1
! P15 61105010000AS AC CORD SET (E3 WHT) U 61105010000AS 1
! P15 61105010100AS AC CORD SET (E2 WHT) N 61105010100AS 1
! P16 61105004200AS OFC AC CORD SET(H20) F 61105004200AS 1
! P16 61105010200AS AC CORD SET (E1C WHT) K 61105010200AS 1 3
P17 nsp POLY COVER U / N / K 00D5050038072 1
P18 32401000800AD MIC AUDYSSEY ACM1HB 32401000800AD 1
P19 nsp AUDYSSEY MIC LABEL 54411042410AS 1
P20 30701016400AM RC027SR REMOTE CONTROLLER 30701016400AM 1
P21 nsp BATTERY (R03X2) EASTPOWER 69105000500AS 1
P22 42911002000AS MIC STAND 42911002000AS 1
★ ns
p
MIC STAND FLY SHEET 54311039300A
D
1
P23 54411039400AM SP CABLE LABEL 54411039400AM 1
P24 nsp ANTENNA LABEL 54411042500AS 1
P25 nsp FM ANTENNA LABEL 54411221400AS 1
P26 nsp CARTON LABEL (U) U 54411221800AM 1 *
P26 nsp CARTON LABEL (N) N 54411221900AM 1 *
P26 nsp LABEL AAC SR7005 A332 F 544110222009M 1
P27 nsp SHEET SERVICE ADRESS(F) F 00M416K851235 1
P28 nsp USER CARD (F) F 00M21AK865019 1
P29 11601005400AS WI-FI ANTENNA(RFDPA870900SBAB801) 11601005400AS 2
P30 nsp WI-FI ANTENNA FLY SHEET 54311038300AS 1
P31 nsp ENVELOPE(ZIPPER B7) 53551020100AS 1
P32 nsp FLY SHEET AV8802 F 54311037400AS 1
P33 nsp CONT LABEL SUB ASSY AV8802 U 8W5451030100M 1 *
P33 nsp CONT LABEL SUB ASSY AV8802 N 8W5451030101M 1 *
P33 nsp CONT LABEL SUB ASSY AV8802 F 8W5451030103M 1 *
P33 nsp CONT LABEL SUB ASSY AV8802A U 8W5451032000M 1 * 3
P33 nsp CONT LABEL SUB ASSY AV8802A N 8W5451032001M 1 * 3
P33 nsp CONT LABEL SUB ASSY AV8802A F 8W5451032003M 1 * 3
P33 nsp CONT LABEL SUB ASSY AV8802A K 8W5451032002M 1 * 3
┣★ ns
p
CONT.LABEL BASE
(
D&M
)
545110022004
S
1
┗★ ns
p
CONT LABEL FILM 545010028003
S
1
P34 nsp MAC ADDRESS SUB ASSY 8W5441032100S 1
┣★ ns
p
SERIAL NO SHEET BASE 00D513417000
5
2
┗★ ns
p
BAR CODE LABEL FILM 00D513332600
9
1
P35 54411222800AD A LABEL (CARTON) AV8802A 54411222800AD 5 * 3
P36 54411222900AD LABEL (HDCP) AV8802A 54411222900AD 2 * 3
★ ns
p
CLEAR LABEL
(
44X12 T0.05
)
U / K 00M32AK861900 1
★ ns
p
LICENSE SUB ASSY
A
V8802 U 8W5441042300D 1
★ ns
p
LICENSE SUB ASSY N 8W5441042301D 1
★ ns
p
LICENSE SUB ASSY F 8W5441042303D 1
★ ns
p
LICENSE SUB ASSY
A
V8802A U 8W5441047601D 1 3
★ ns
p
LICENSE SUB ASSY
A
V8802A K 8W5441042302D 1 3
┣★ ns
p
ITF LABEL FILM 00D513410900
5
123㎜
┗★ ns
p
ITF LABEL BASE 54411032000AS 1
★ ns
p
A
NTENNA ISOLATOR K 18901004900AS 1 3
★ ns
p
WARRANTY CHINA MZ K 54311016220AM 1 3
