61
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
C403 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C405 nsp ELECT 470
F6.3V M nsp
C406 nsp TUBULAR 0.01
F 16V M nsp
C407 nsp ELECT 22
F16V M nsp
C408 nsp ELECT 10
F16V M nsp
C409 nsp ELECT 470
F6.3V M nsp
C410 nsp ELECT 22
F16V M nsp
C411 nsp TUBULAR 1000pF 50V K nsp
C412 nsp TUBULAR100pF 50V J nsp
C413 nsp ELECT 10
F16V M nsp
C414 nsp TUBULAR 0.1
F 50V
+80% -20%
nsp
C415 nsp ELECT 10 16V M nsp
C416 nsp TUBULAR 1000pF 50V K nsp
C417 nsp TUBULAR100pF 50V J nsp
C418 nsp TUBULAR 3900pF 16V M nsp
C419 nsp ELECT 22 16V M nsp
C420 nsp TUBULAR 3900pF 16V M nsp
C421 nsp ELECT 22 16V M nsp
C422 nsp ELECT 10 16V M nsp
C424 nsp TUBULAR 0.1
F 50V
+80% -20%
nsp
C425 nsp TUBULAR 0.01
F 16V M nsp
C428 nsp TUBULAR 0.1
F 50V
+80% -20%
nsp
C429 nsp ELECT 47
F 16V M nsp
C430 nsp ELECT 47
F 16V M nsp
C502 nsp CER. 0.01
F 50V K nsp
C503 nsp CHIP CER. 0.1
F
F
F
F
F
50V Z nsp
C504 nsp CER. 2.2
F 16V +80% -20% nsp
C505 nsp CHIP CER. 0.1
F 50V Z nsp
C506 nsp CER. 2.2
F 16V +80% -20% nsp
C508
nsp CHIP CER.0.1 F 50V Z nsp
C522
C523 nsp CER. 2.2
F 16V +80% -20% nsp
C525
nsp CHIP CER. 0.1 F 50V Z nsp
C536
C537 nsp CHIP CER. 220pF 50V J nsp
C538 nsp CER. 2.2
F 16V +80% -20% nsp
C540 nsp CHIP CER. 15pF 50V J nsp
C541 nsp CHIP CER. 27pF 50V J nsp
C542 nsp CHIP CER. 0.1
F 50V Z nsp
C543 nsp CHIP CER. 0.1
F 50V Z nsp
C544 nsp CER. 2.2
F 16V +80% -20% nsp
C546 nsp CHIP CER. 220pF 50V J nsp
C548 nsp CHIP CER.220pF 50V J nsp
C549 nsp CHIP CER. 220pF 50V J nsp
C550 nsp CHIP CER. 0.1
F50V Z nsp
C553 nsp CHIP CER. 220pF 50V J nsp
C556 nsp ELECT 10
F 16V M nsp
C601 N nsp ELECT 22
F 16V M nsp
C602 N nsp ELECT 47
F16V M nsp
C603 nsp ELECT 470
F6.3V M nsp
C604 N nsp ELECT 22
F16V M nsp
C605 N nsp TUBULAR 0.01
F16V M nsp
C606 nsp TUBULAR 0.1
F
F
50V
+80% -20%
nsp
C609 N nsp ELECT 47 16V M nsp
C611 nsp TUBULAR 220pF 50V K nsp
C612 nsp TUBULAR 0.1
F 50V
+80% -20%
nsp
C613 nsp ELECT 470
F 6.3V M nsp
C614 nsp ELECT 470
F 6.3V M nsp
C615 nsp ELECT 470
F 6.3V M nsp
C616 N nsp TUBULAR 3900pF 16V M nsp
C617 N nsp TUBULAR 3900pF 16V M nsp
C650 N nsp ELECT 47
µ
F 16V M nsp
C652 N nsp TUBULAR 0.01
µ
F 16V M nsp
C653
N nsp ELECT 10
µ
F 16V M nsp
C657
C660 N nsp ELECT 10 F 16V M nsp
C661 N nsp ELECT 10 F 16V M nsp
C662 N nsp ELECT 10 F 16V M nsp
C663 N nsp ELECT 470 F 6.3V M nsp
C901 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C902 nsp ELECT 10 16V M nsp
C905 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C906 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C907 nsp ELECT 47 F 16V M nsp
C908 nsp ELECT 47 F 16V M nsp
C909 nsp .ELECT 47 F 35V M nsp
C910 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C911 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C912 nsp ELECT 47 16V M nsp
C913 nsp TUBULAR 0.1 F 50V
+80% -20%
nsp
C914 nsp ELECT 47 16V M nsp
DIODES
BD101 4822 130 81248 S1WBA60(1A 600V) *HD201400R
D101 F, U nsp SUF4005 R *HD201610R
D101 N, A, S 9965 000 11316 10SP07U(SUF4007SP) *HD201620R
D102 N, A, S 9965 000 06965 EU01W(R-FORM) *HD201390R
D103 F, U 4822 130 32778 1SS133 DETECT SW HD20015210
D104 F, U 4822 130 32778 1SS133 DETECT SW HD20015210
D105 F, U nsp RL104 R *HD201430R
D106 9965 000 11317 HER202 BK NON 100V 2A *HD201630R
D107 N, A, S 9965 000 06965 EU01W(R-FORM) *HD201390R
D107 F, U 9965 000 06971 ERA18-02KFRB DO204AL 2 *HD201460R
D108 9965 000 06965 EU01W(R-FORM) *HD201390R
D109 9965 000 06968 B10A45V1 BK KEC TO220
45V 10A
*HD201440R
D110 9965 000 06971 ERA18-02KFRB DO204AL 2 *HD201460R
D112 4822 130 33765 1N5402 BK *HD201450R
D113 4822 130 33765 1N5402 BK *HD201450R
D115 (P-2) 9965 000 11318 1N17 NON 20V 1A 20 *HD201600R
D115 (P2 LE) nsp WIRE D=0.6 ROLL nsp
D116 F, U nsp RZ1040 BK DO41 40V 30A *HD201420R
D2A1 4822 130 33944 DAN202K SOT23 80 HZ20002210
D2A2 4822 130 33944 DAN202K SOT23 80 HZ20002210
D301 4822 130 33944 DAN202K SOT23 80 HZ20002210
D302 4822 130 33944 DAN202K SOT23 80 HZ20002210
D601 N 4822 130 32778 1SS133 DETECT, SW HD20015210
D602 N 4822 130 32778 1SS133 DETECT, SW HD20015210
D603 4822 130 32778 1SS133 DETECT, SW HD20015210
D604 4822 130 32778 1SS133 DETECT, SW HD20015210
D605 N 4822 130 32778 1SS133 DETECT, SW HD20015210
D909 4822 130 32778 1SS133 DETECT, SW HD20015210
DIG901 9965 000 11319 DIGION VFD20-0703FNA
ZEC SEG VFD
*HQ300530R
LED01 9965 000 11335 LED LTL-1CHEES-UA RED =0 *HI100990R
LED02 9965 000 11336 LED LTL-1CHKES-UA GREEN *HI101000R
LED03 9965 000 11335 LED LTL-1CHEES-UA RED =0 *HI100990R
LED901 9965 000 04671 LE SPR325MVWT31
GREEN/RED
*HI100860R
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
