Marantz DV4200 - Page 48

62
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
ZD101 F, U 9965 000 11344 ZENER GDZJ3.3B DO34 0.5W *HD302010R
ZD101 N, A, S 5322 130 31504 ZENER UZ-3.3BSB 26MM *HD302020R
ZD102 F, U nsp ZENER GDZJ6.2B 26MM DO34 *HD302030R
ZD605 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD606 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD607 N 9965 000 11343 ZENER GDZJ10B 26MM DO34 *HD302040R
ZD611
F, A, S, U 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD612
F, A, S, U 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD635 N 9965 000 11344 ZENER GDZJ3.3B DO34
0.5W 3
*HD302010R
ZD635
F, A, S, U 5322 130 31504 ZENER UZ-3.3BSB 26MM *HD302020R
ZD636 N 9965 000 11344 ZENER GDZJ3.3B DO34
0.5W 3
*HD302010R
ZD636
F, A, S, U 5322 130 31504 ZENER UZ-3.3BSB 26MM *HD302020R
ZD637 N 9965 000 11344 ZENER GDZJ3.3B DO34
0.5W 3
*HD302010R
ZD637
F, A, S, U 5322 130 31504 ZENER UZ-3.3BSB 26MM *HD302020R
ZD638 N 9965 000 11344 ZENER GDZJ3.3B DO34
0.5W 3
*HD302010R
ZD638
F, A, S, U 5322 130 31504 ZENER UZ-3.3BSB 26MM *HD302020R
ZD639 N 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD640 N 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD641
F, A, S, U 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD642 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD643 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD644 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD901 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
ZD902 9965 000 07022 ZENER GDZJ5.6B 26MM DO34 *HD301840R
INTEGRATED CIRCUITS
4822 252 51025 IC ICP-N10 T104 IC DETACT FU40115020
F
F102
104 4822 252 51083 IC ICP-N20 T104 IC DETACT FU80115020
IC101 N, A, S 9965 000 11320 IC KA5M0365R-YDTU *HC107420R
IC102 N, A, S 9965 000 11321 SENSOR PHOTO KP1010
COSMO =PC817
*HC200150R
IC104 4822 209 81397 IC KA431AZ (LM431AZ) *HC105750R
IC105 9965 000 06979 IC KA78R08 4P TO-220F BK
LOW DROP
*HC300250R
IC106 9965 000 11322 IC KA78R33TU TO220-4L
BK 3.3V L/D
*HC300260R
IC107 9965 000 11322 IC KA78R33TU TO220-4L
BK 3.3V L/D
*HC300260R
IC108 F, U 9965 000 11321 SENSOR PHOTO KP1010
COSMO =PC817
*HC200150R
IC201 9965 000 11323 IC GDC25D801D 208 QFP
BK DSP+SERV
*HC107430R
IC203 4822 209 90472 IC NJM3414AM-TE1 HC10179090
IC204 9965 000 11324 IC KIC7W53FU KEC 8PIN SM8 *HC107440R
IC205 9965 000 06985 IC GLT440L16-40J4 40P
SOJ 4M
*HC106620R
IC206 4822 209 33521 IC TC7W04FU HC10382050
IC2A1 9965 000 06986 IC SSI33P3721(VER.2)
64 TQFP BK R
*HC105760R
IC2A2 4822 209 90472 IC NJM3414AM-TE1 HC10179090
IC2M1 9965 000 11325 IC FAN8727 48PIN QFP *HC107510R
IC301 9965 000 11326 IC XC9572XL-10TQ100C 100
QFP AY
*HC107460R
IC302 9965 000 11327 IC 74LCX573MTCX 20P TSS *HC700420R
IC303 9965 000 11327 IC 74LCX573MTCX 20P TSS *HC700420R
IC305 9965 000 11328 IC HY57V653220CTC-7
86P TSOP BK S
*HC107470R
IC3F1 nsp IC AT49BV1614-11TC
48PIN TS
*HC107490R
IC401 8203 303 11278 IC PCM1716E 28P SSOP
DAC 2K/R
*HC105580R
IC402 4822 209 73953 IC NJM4580D JRC 8 DIP
ST SWITCHIN
HC10070090
IC403 4822 209 16953 IC KA78R12 TO-220 LD
1A REGL
*HC107520R
IC501 nsp IC NDV8501VWB 240 VQFP AY
MICOM
nsp
IC502 nsp IC CAT93C56S-TE13 *HC107480R
IC502P NnspPROGRAM
ADVD3520NC.1UM1
nsp
IC502P A, S nsp PROGRAM
ADVD3500EC.3GM1
nsp
IC502P UnspPROGRAM
DV4200(DVM4511N)
nsp
IC502P F nsp PROGRAM DVM4511N nsp
IC503 9965 000 11329 IC MM74HCT244SJ 20P
SOIC 3-STA
*HC700430R
IC505 4822 209 33521 IC TC7W04FU HC10382050
IC506 IC BA18BC0FP-E2 RW
3P TO252-3 R
*HC107570R
IC601 N 9965 000 11330 IC NJM2284 JRC 16PIN DIP
ST SCART
*HC107530R
IC901 9965 000 11331 IC UPD780232GC-043-8BT
80 QFP
*HC107500R
IC902 9965 000 06999 IC KIA7042P 3P 4.2V RESET *HC105670R
TRANSISTORS
Q101 F, U nsp KSE13005F BK TO220F *HT300910R
Q102 F, U nsp KTC3198-BL (KTC1815) *HT300720R
Q107 9965 000 07007 KSB1151-Y BK TO-126 *HT200390R
Q108 4822 130 10923 KTC3199-BL MINI *HT300730R
Q2A1 9965 000 04336 CHIP 2SA1037K-Q HX110371A0
Q2A2 9965 000 04336 CHIP 2SA1037K-Q HX110371A0
Q2M1 4822 130 60729 DTC124EK SOT23 *BA001080R
Q401 4822 130 10462 KTA1267-GR MINI *HT100490R
Q402 4822 130 10462 KTA1267-GR MINI *HT100490R
Q403
4822 130 10923 KTC3199-BL MINI *HT300730R
Q407
Q507 9965 000 07008 UMZ1N TL UM6 3K BA30002210
Q601 N 4822 130 10462 KTA1267-GR MINI *HT100490R
Q602 N 4822 130 10098 KRC103M- (KRC1203) *HT300790R
Q603 N 4822 130 10098 KRC103M- (KRC1203) *HT300790R
Q604 N 4822 130 10098 KRC103M- (KRC1203) *HT300790R
Q605 N 4822 130 10462 KTA1267-GR MINI *HT100490R
Q606 N 4822 130 10462 KTA1267-GR MINI *HT100490R
Q607 4822 130 10923 KTC3199-BL MINI *HT300730R
Q608 4822 130 10923 KTC3199-BL MINI *HT300730R
Q615 4822 130 10462 KTA1267-GR MINI *HT100490R
Q616 N 4822 130 10462 KTA1267-GR MINI *HT100490R
Q617 N 4822 130 10923 KTC3199-BL MINI *HT300730R
Q618 N 4822 130 10923 KTC3199-BL MINI *HT300730R
Q619 N 4822 130 10923 KTC3199-BL MINI *HT300730R
Q901 4822 130 10145 KRA103M- (KRA2203) *HT100630R
Q902 4822 130 10923 KTC3199-BL MINI *HT300730R
Q903 4822 130 10462 KTA1267-GR MINI *HT100490R
RESISTORS
R101 nsp CEMENT 2.7
2W nsp
R104 F, U nsp METAL 33k
2 W J GA05332020
R104 N, A, S 9965 000 07013 METAL 56k
2 W J GA05563020
R109 F, U nsp FILM 15k
1/6 W J nsp
R110 F, U 4822 053 10121 METAL 120
1 W J GA05121010
R111 F, U nsp METAL 1
2 W J GA05010020
R112 N, A, S nsp FILM 3.9
1/6 W J nsp
R112 F, U nsp FILM 8.2k
1/6 W J nsp
R114 nsp FILM 100k
1/6 W J nsp
R115 F, U nsp FILM 4.7
1/6 W J nsp
R115 N, A, S nsp FILM 5.6
1/6 W J nsp
R117 F, U nsp FILM 100
1/6 W
W
Jnsp
R120 nsp FILM 1k
1/6 J nsp
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
