Marantz PM-14S1 Manual Del Usuario

25
Preparación Conexiones Reproducción Ajustes Consejos Apéndice
ESPAÑOL
• Salida de potencia RMS:
(20 Hz – 20 kHz simultáneo en 2 canales)
90 W × 2 (8 Ω/ohm)
140 W × 2 (4 Ω/ohm)
• Distorsión armónica total:
(20 Hz – 20 kHz simultáneo en 2 canales, 8 Ω/
ohm)
0,05%
• Ancho de banda de salida: (8 Ω/ohm, 0,05%) 5 Hz − 40 kHz
• Frecuencia de respuesta:
(CD, 1 W, carga de 8 Ω/ohm)
5 Hz − 100 kHz ± 3 dB
• Factor de amortiguación:
(8 Ω/ohm, 20 Hz − 20 kHz)
100
• Sensibilidad de entrada/impedancia de
entrada
PHONO (MC): 270 µV/100 Ω/ohm
PHONO (MM): 2,7 mV/47 kΩ/kohm
CD/LINE: 240 mV/20 kΩ/kohm
P. DIRECT IN: 1,7 V/20 kΩ/kohm
• Voltaje de salida/impedancia de salida
PRE OUT: 1,7 V/220 Ω/ohm
• Nivel de entrada PHONO máxima admisible
(1 kHz)
MC: 15 mV
MM: 150 mV
• Variación RIAA: (20 Hz−20 kHz) ± 0,5 dB
• S/R (IHF-A, 8 Ω/ohm)
PHONO (MC): 75 dB (0,5 mV entrada, 1 W salida)
PHONO (MM): 86 dB (5 mV entrada, 1 W salida)
CD/LINE: 106 dB (2 V entrada, salida nominal)
• Control de tonalidad
BASS (50 Hz): ± 10 dB
TREBLE (20 kHz): ± 10 dB
• Requisitos de alimentación: CA 120 V, 60 Hz
• Consumo de energía (UL60065): 220 W
• Consumo energético en modo de espera: 0,2 W
Con el fin de introducir mejoras, las especificaciones y el diseño del equipo están sujetos a
cambios sin previo aviso.
Especificaciones
v A
Accesorios ····························································1
Ajuste del tono ··················································· 17
Ajuste del volumen ············································· 16
v C
Cables necesarios para las conexiones ················ 7
Circuito de protección ········································ 24
Conexión
Altavoz ·······························································8
Amplificación doble completa en estéreo ·········11
Amplificador de potencia ································· 14
Cable de alimentación······································ 15
Conectores del mando a distancia ··················· 15
F.C.B.S. ····························································· 10
Grabadora ·························································· 9
Preamplificador ················································ 14
Reproducción multicanal 5.1 ···························· 12
Reproductor ······················································· 8
Consejos ···························································· 20
v E
Encendido ·························································· 16
v I
Impedancia de altavoces ···································· 24
Interrupción temporal del sonido ························ 17
v M
Mando a distancia ················································ 6
Inserción de las pilas·········································· 2
Modo de espera automático ······························ 19
v P
Panel delantero ·····················································4
Panel trasero ························································5
v R
Resolución de problemas ··································· 20
v S
Selección de cápsula MM/MC ··························· 24
Selección de la fuente de entrada ······················ 16
Índice
3.PM14S1U_ESP_0725.indd 25 2013/07/25 17:19:52

Marantz PM-14S1 Specifications

General

Receiver type	-
Frequency range	5 - 100000 Hz
Pre-out connectivity	Yes
Audio output channels	2.0 channels
Total Harmonic Distortion (THD)	0.02 %
Dynamic power per channel (4 Ohm)	140 W
Dynamic power per channel (8 Ohm)	90 W
Power output per channel (20-20KHz@8 Ohm)	- W
Headphone outputs	1
Headphone connectivity	6.3 mm
Ethernet LAN	No
Display	LCD
Product color	Gold
Apple docking compatibility	Not supported
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W
Cables included	AC

Weight and Dimensions

Depth	453 mm
Width	440 mm
Height	123 mm
Weight	18500 g
