Marantz PS-17 - Page 33

51
no
yes
no no no
yes yes yes
no no
yes yes
No sound
from SPK on
AC-3/DTS decode
6ch Direct
is OK ?
Test tone is
OK ?
Pre output is
OK ?
Encode
status LED
shows ?
Encode
status LED
shows ?
DAC & DSP are no problem
Decoding is no problem
P604 has trouble
96k PCM is
OK?
L/R DAC is no problem
DIR & Q601input is no
DIR:QR01 or
DSP:Q601(P604)
has any problem.
DIR(QR01) or QR06
has any problem.
To be check
signal(SDIDR)
Error Mute circuite
has problem.
To be check QR04
Front L/R DAC circuite(P601)
has any problem.
To be check Q606.
DSP:Q601(P601)
output stage or other ch
DAC(QD02,03,04) has
problem.
To be check Q606.
6ch SW(PS04,PC04)),
Volume, I/V amp(PG04)
has any problem.
to be check Main in
at SPK Output
no
yes
no no no
yes yes yes
no
yes
No sound
from SPK on
analog Dolby
6ch Input
is OK ?
Test tone is
OK ?
Pre output is
OK ?
DAC & DSP-out are no problem
Decoding is no problem
P604 has trouble
Q601& DAC are no problem
Digital PCM
ProLogic is
OK ?
Digital PCM
ProLogic is
OK ?
to be check Main in
at SPK Output
6ch SW(PS04,PC04),
Volume, I/V amp(PG04)
has any problem.
DIR(QR01) or QR06
has any problem.
To be check
signal(SDIDR)
ADC(QK01) has any problem.
QK01 can not output data.
To be check QK01 or Lt/Rt input
on P604
DSP:Q601or
DAC:QD01,02,03,04(P604)
has any problem.
Clock output form DSP:Q601
has any problem.
