8. EXPLODED VIEW AND PARTS LIST
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
001B /F FRONT PANEL AL GOLD 330J248110
001B /L, /S FRONT PANEL AL GOLD S 330J248140
001B /N 9965 000 09139 FRONT PANEL AL GOLD N 330J248130
002B 9965 000 01554 BADGE MZ GOLD 313J251110
003B 9965 000 09140 FRONT PANEL MOULD GOLD 330J248120
005B 9965 000 09141 WINDOW GOLD 330J158010
006B 4822 381 11893 LENS FUNCTION 269J355010
007B 9965 000 09142 ESCUTCHEON CONER GOLD 330J063110
009B /F,/L,/S ESCUTCHEON METER GOLD 289J063120
009B /N 4822 532 13059 ESCUTCHEON METER GLD N 289J063110
011B /F BADGE SUPER AUDIO 318J251010
011B /L,/S BADGE S. A 313J251020
012B 4822 381 12016 LENS IR GOLD 256J355030
013B 4822 381 11677 LENS POWER 230K355020
015B 9965 000 09144 BUTTON GOLD 330J270110
016B 9965 000 09145 ARM HINGE DOOR L GOLD 330J002110
017B 9965 000 09146 ARM HINGE DOOR R GOLD 330J002120
018B 9965 000 01801 SHAFT DOOR 300J112010
021B 9965 000 09147 DAMPER DOOR 391H130010
023B /F DOOR PANEL GOLD 330J162110
023B /L,/N,/S 9965 000 09148 DOOR PANEL GOLD BLAST 330J162120
026B 4822 526 20213 MAGNET DOOR MAGNET 271K305500
028B SPRING DOOR ESD 330J115010
029B 9965 000 09149 BUSHING L R 330J259110
040B 9965 000 09150 KNOB MASTER 330J154110
041B 9965 000 09151 KNOB FUNCTION GOLD 330J154120
042B 4822 410 11276 BUTTON POWER 176J270150
043B 4822 404 21012 JOINT LINK POWER BUTTON 025J125010
044B 4822 256 92097 HOLDER FL 183J271020
062B 9965 000 09152 MASK IR 300J303030
070B WASHER 245S012020
001D 9965 000 09153 LID TOP GOLD 330J257110
002D 9965 000 06313 SCREW SCR.TOP LID 323S010040
003D 9965 000 09154 SIDE PANEL 330J249110
004D 4822 502 14613 SCREW SCR.SIDE PANEL 258S010020
062G 4822 462 42134 LEG 291K057010
C001 9965 000 09106 ELECT. CAP.
5000µF 63V GOLD TUNE
OB15906330
C002 9965 000 09106 ELECT. CAP.
15000µF 63V GOLD TUNE
OB15906330
J003 4822 265 11399 JACK 2P AC INLET SOT-16C YJ04002360
J011 4822 265 11424 TERMINAL WBT-0765 RED YT01010360
J012 4822 265 11424 TERMINAL WBT-0765 RED YT01010360
J013 4822 265 11425 TERMINAL WBT-0765 WHT YT01010370
J014 4822 265 11425 TERMINAL WBT-0765 WHT YT01010370
L001 /F MAINS TRANSF. R-400
100V 50/60Hz
TS42002160
L001 /L MAINS TRANSF. R-400
110V 60Hz
TS42002190
L001 /N,/S 9965 000 09107 MAINS TRANSF. R-400
230V 50Hz EMC
TS42002180
L002 /F MAINS TRANSF. R-25D
R-CORE FOR F
TS72502010
L002 /L MAINS TRANSF. R-25D
R-CORE 110V 60Hz
TS72502030
L002 /N,/S 9965 000 09108 MAINS TRANSF. R-25D
R-CORE FOR N
TS72502020
L003 4822 526 10691 FERRITE CORE TFCK-16-8-13 FC50160030
L601 4822 526 10691 FERRITE CORE TFCK-16-8-13 FC50160030
L603 4822 526 10691 FERRITE CORE TFCK-16-8-13 FC50160030
PACKING
001T /F USER GUIDE FOR F 330J851110
001T /L,/S USER GUIDE FOR S 330J851350
001T /N 9965 000 09155 USER GUIDE FOR N 330J851310
Z001 9965 000 09138 REMOTE COMMANDER
RC-17PS
ZK330JSRR
Z008 /F,/L 4822 321 11337 MAINS CORD
MITY DC-302-J 125V 12A
ZC01802080
Z008 /N 4822 321 11033 MAINS CORD
AC 250V 10A CLASS-2
ZC01803080
Z008 /S MAINS CORD
AC 250V 10A FOR UK
ZC01804100
NOT STANDARD SPARE
PARTS
001S /F PACKING CASE 330J801010
002S CUSHION L 330J809010
003S CUSHION R 330J809020
*
