Marantz PS-17 - Page 37

55
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PB04-BACK UP SUPPLY
CIRCUIT BOARD
PB04-CAPACITORS
CB01 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB02 4822 124 22276 ELECT. 47µF M 50V RA-2 OA47605020
CB03 4822 124 90355 ELECT. 100µF M 50V RA-2 OA10705020
CB04 4822 124 23068 ELECT. 220µF M 63V RA-2 OA22706320
CB05 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB06 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB07 4822 124 41541 ELECT. 470µF M 35V RA-2 OA47703520
CB08 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB09 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB10 4822 124 22722 ELECT. 1000µF 16V M RA-2 OA10801620
CB11 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB12 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CB13 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB15
4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB19
CB20 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB21 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB22
4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB25
CB26 4822 124 12328 ELECT. 6800µF 16V RA2 OA68801620
CB27 4822 124 12328 ELECT. 6800µF 16V RA2 OA68801620
CB28 4822 124 22277 ELECT. 470µF 16V M RA-2 OA47701620
CB29 4822 124 22277 ELECT. 470µF 16V M RA-2 OA47701620
CB30
4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB33
CB34
4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB37
CB38
4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CB41
CB42 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB43 4822 122 30043 CER. 0.01µF Z 50V DK18103310
CB44 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB45 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
PB04-RESISTORS
RB03 4822 053 10561 560
Ω
±5% 1W GA05561010
RB04 4822 117 10158 1
Ω
±5% 1/4W GG05010140
RB05 4822 117 10158 1
Ω
±5% 1/4W GG05010140
RB99 4822 116 83963 2.2
Ω
±5% 1/4W GG05022140
PB04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :RB02 RB02
RB07-RB11 RB13
PB04-SEMICONDUCTORS
DB01 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB02 4822 130 80318 ZENER DIODE 6.8V HD30681000
DB03
4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB11
DB14 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB15 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB16 4822 130 83067 DIODE D3SB20 3A 200V HE20020290
DB19 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB20 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB21 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB22 4822 116 82805 RES. 1
Ω
±5% 1/6W GG05010160
DB25 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB26 4822 116 82805 RES. 1
Ω
±5% 1/6W GG05010160
QB01 9965 000 09110 TRS. 2SA950 GR OR R HT109501A0
QB02 9965 000 09110 TRS. 2SA950 GR OR R HT109501A0
QB04 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
QB05 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
QB07 4822 209 83824 IC NJM7805FA +5V HC38905090
QB08 4822 209 15921 IC RESET S-806D-Z SEIKO HC10077530
QB09 4822 209 83824 IC NJM7805FA +5V HC38905090
QB10 4822 209 83824 IC NJM7805FA +5V HC38905090
QB11 4822 209 83824 IC NJM7805FA +5V HC38905090
QB12 4822 209 30258 IC NJM7905FA HC39905090
PB04-MISCELLANEOUS
JB01 PLUG VH-8P SIDE YP06011080
LB03 9965 000 05895 RELAY G5PA-28 5A/250VAC LY20240490
LB04 9965 000 05895 RELAY G5PA-28 5A/250VAC O LY20240490
PC04 ELE.VOL./6CH SW
CIRCUIT BOARD
PC04-CAPACITORS
CF01 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CF01 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CF02 4822 124 90362 ELECT. 22µF 50V OA22605020
CF03 4822 122 40617 CER. 0.1µF 50V DD38104010
CF04 4822 122 40617 CER. 0.1µF 50V DD38104010
CF05 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CF06 4822 124 22698 ELECT. 47µF M 25V RA-2 OA47602520
CF07 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CF07 /L 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CF07 /N 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CF07 /S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CF08 4822 124 90362 ELECT. 22µF 50V OA22605020
CF09 9965 000 01344 FILM 100pF J 100V OF15101540
CF10 4822 121 10792 FILM 220pF J 100V OF15221540
CF11 4822 124 90362 ELECT. 22µF 50V OA22605020
CF12 4822 124 90362 ELECT. 22µF 50V OA22605020
CF13 4822 123 30086 MICA 47pF J 500V DF35470520
CF14 4822 123 30086 MICA 47pF J 500V DF35470520
CF15 /F 4822 124 90362 ELECT. 22µF M 50V RA-2 OA22605020
CF15 /L,/N,/S 4822 124 80578 ELECT. 22µF 25V ARA OA22602550
CF16 4822 124 90362 ELECT. 22µF 50V OA22605020
CF17 9965 000 05891 FILM 470pF J 100V OF15471540
CF18 9965 000 05891 FILM 470pF J 100V OF15471540
CF19 4822 121 10792 FILM 220pF J 100V OF15221540
CF20 4822 121 10792 FILM 220pF J 100V OF15221540
CF21 4822 124 41535 ELECT. 100µF 25V OA10702520
CF22 4822 124 41535 ELECT. 100µF 25V OA10702520
CF23 4822 122 40586 CER. 10000pF DA17103110
CF24 4822 122 40586 CER. 10000pF DA17103110
CF29 4822 122 40617 CER. 0.1µF 50V DD38104010
CF51 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF51 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF52 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF52 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF53 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF53 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF54 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF54 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF55 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF55 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF56 /F,/L 9965 000 01344 FILM 100pF J 100V APSV OF15101540
CF56 /N,/S 9965 000 05891 FILM 470pF 100V PP OF15471540
CF57 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CF58 4822 122 40617 CER. 0.1µF 50V DD38104010
CF59 4822 122 40617 CER. 0.1µF 50V DD38104010
CF60 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CF61 4822 121 10792 FILM 220pF J 100V OF15221540
CF62 4822 121 10792 FILM 220pF J 100V OF15221540
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
