Marantz SA-7S1f - Page 32

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-46
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PA16 C327 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
PA16 C328 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C351 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
PA16 C352 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
PA16 C353 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C371 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C372 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C376 00MDF95331500 00MDF95331500 CHIP MICA UC342H3300J 330PF 500WV
PA16 C377 00MDF95151500 00MDF95151500 CHIP MICA UC342H1500J 150PF 500WV
PA16 C378 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C402 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
PA16 C403 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C405 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C406 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C421 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C422 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C427 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
PA16 C428 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C430 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C431 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C452 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
PA16 C453 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C455 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C456 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C471 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C472 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C477 00MDF91100500 00MDF91100500 CHIP MICA UC232H0100D 10PF 500WV
PA16 C478 00MDF95330500 00MDF95330500 CHIP MICA UC232H0330J 33PF 500WV
PA16 C480 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C481 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PA16 C841 00MOB10803530 00MOB10803530 ELECT CAP. 1000UF 35V SPECIAL
(
LF
)
PA16 C842 ns
p
00MOA107025R0 ELECT CAP. ROA-25V 101M-H4#PE
(
100UF 25V
)
PA16 C843 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C851 00MOB47803590 00MOB47803590 ELECT CAP. 4700U 35V
(
LAO
)(
LF
)
AQL-0298
PA16 C852 00MOB47803590 00MOB47803590 ELECT CAP. 4700U 35V
(
LAO
)(
LF
)
AQL-0298
PA16 C853 ns
p
00MOA107025R0 ELECT CAP. ROA-25V 101M-H4#PE
(
100UF 25V
)
PA16 C854 ns
p
00MOA107025R0 ELECT CAP. ROA-25V 101M-H4#PE
(
100UF 25V
)
PA16 C855 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 C856 ns
p
00MOA477025R0 ELECT CAP. ROA-25V 471M-I6#PE
(
470UF 25V
)
PA16 CN06 ns
p
00MOA47602520 ELECT CAP. 47 UF M 25V RA-2
PA16 CN08 ns
p
00MOA10702520 ELECT CAP. 100 UF M 25V RA-2
PA16 CN10 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PA16 D101 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D102 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 D201 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D202 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D226 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D227 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D251 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D252 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D276 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D277 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D301 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D302 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D326 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D327 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D351 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D352 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D376 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D377 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D401 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D402 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D403 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D404 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D426 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D427 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D428 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
