Marantz SA-7S1f - Page 33

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-47
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PA16 D429 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D451 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D452 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D453 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D454 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D476 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA16 D477 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D478 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D479 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TE85L,F
)
PA16 D841 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D842 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D843 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D844 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D845 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 D846 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
PA16 D851 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D852 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D853 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D854 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D855 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D856 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D857 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D858 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PA16 D859 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 D860 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 D861 00MHD30021010 00MHD30021010 ZENER DIODE ZENER HZ6A3L
PA16 D862 00MHD30021010 00MHD30021010 ZENER DIODE ZENER HZ6A3L
PA16 DN19 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
PA16 DN20 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN22 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN23 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN24 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN25 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 DN26 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT
PA16 J806 00MYP10004500 00MYP10004500 PLUG 10PL-FJ
(
10P PLUG FJ-L
)
PA16 L101 00MLU12222010 00MLU12222010 CHIP INDUCT. NL322522-2R2M
PA16 L103 00MFM12223030 00MFM12223030 EMI FILTER NFM41R10C223T1/B1 EMI FILTER
PA16 L131 00MFM12223030 00MFM12223030 EMI FILTER NFM41R10C223T1/B1 EMI FILTER
PA16 L133 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-T
PA16 L151 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PA16 L180 00D2350147909 00D2350147909 EMI FILTER E.FIL
(
BLM21PG221SN1
)
+2125
PA16 L181 00D2350147909 00D2350147909 EMI FILTER E.FIL
(
BLM21PG221SN1
)
+2125
PA16 L201 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-T
PA16 L251 00MFC90020100 00MFC90020100 FERRITE CORE FB M J2125HM330-T
PA16 LN21 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 LN22 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 LN23 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 LN24 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 LN25 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 LN26 00MLY20120650 00MLY20120650 RELAY UA2-12NU
PA16 Q101 00MHC10250990 00MHC10250990 IC XC2S15-5VQ100C FPGA
PA16 Q102 00MHJ27AKX200 00MHJ27AKX200 EPROM/EEPROM XCF01SV020C FOR SA-7S1
PA16 Q103 00MHC012405K0 00MHC012405K0 IC TC7SGU04FE
(
TE85L F
PA16 Q104 00MHC012405K0 00MHC012405K0 IC TC7SGU04FE
(
TE85L F
PA16 Q105 00MHC012405K0 00MHC012405K0 IC TC7SGU04FE
(
TE85L F
PA16 Q106 00MHC98403980 00MHC98403980 IC XC6203P332PR 3.3V 0.4A REG.
PA16 Q107 00MHC98102090 00MHC98102090 IC NJM2880U25-TE1 2.5V REG
PA16 Q109 00MHC96303320 00MHC96303320 IC PQ1U331M2ZPH 3.3V 300MA
PA16 Q110 00MHC96303320 00MHC96303320 IC PQ1U331M2ZPH 3.3V 300MA
PA16 Q111 00MHC10114170 00MHC10114170 IC DSP56364FU100 AUDIO DSP
PA16 Q112 00MHC10436050 00MHC10436050 IC TC7SH86FU
PA16 Q113 00MBA20035210 00MBA20035210 TRS. DTC114EU
PA16 Q114 00MHJ27AKX30F 00MHJ27AKX30F EPROM/EEPROM AT49BV040B-TU FOR SA-7S1
PA16 Q115 00MBA21303000 00MBA21303000 TRS. DTC124EU,RN1303 UMT
PA16 Q116 00MHX300012B0 00MHX300012B0 CHIP TRS. 2SC4081
(
R.S
)
2SC4116
(
GR.BL
)
PA16 Q117 00MHX300012B0 00MHX300012B0 CHIP TRS. 2SC4081
(
R.S
)
2SC4116
(
GR.BL
)
