NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-53
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PA16 R464 ns
p
00MGM11446420 CHIP RES. 46.4K OHM +-1% 1/4W
PA16 R466 ns
p
00MGM11410000 CHIP RES. 100 OHM +-1% 1/4W
PA16 R467 ns
p
00MGM11446400 CHIP RES. 464 OHM +-1% 1/4W
PA16 R468 ns
p
00MGM11417800 CHIP RES. 178 OHM +-1% 1/4W
PA16 R469 ns
p
00MGM11446400 CHIP RES. 464 OHM +-1% 1/4W
PA16 R470 ns
p
00MGM11417800 CHIP RES. 178 OHM +-1% 1/4W
PA16 R472 ns
p
00MGM114100G0 CHIP RES. 10 OHM +-1% 1/4W
PA16 R473 ns
p
00MGM114100G0 CHIP RES. 10 OHM +-1% 1/4W
PA16 R474 ns
p
00MGM114464G0 CHIP RES. 46.4 OHM +-1% 1/4W
PA16 R475 ns
p
00MGM11410030 CHIP RES. 100K OHM +-1% 1/4W
PA16 R476 ns
p
00MGM11422610 CHIP RES. 2.26K OHM +-1% 1/4W
PA16 R477 ns
p
00MGM11430110 CHIP RES. 3.01K OHM +-1% 1/4W
PA16 R478 ns
p
00MGM11475010 CHIP RES. 7.5K OHM +-1% 1/4W MELF
PA16 R479 ns
p
00MGM11468110 CHIP RES. 6.81K OHM +-1% 1/4W
PA16 R480 ns
p
00MGM11491010 CHIP RES. 9.1K OHM +-1% 1/4W MELF
PA16 R481 ns
p
00MGM11422620 CHIP RES. RN412ETTE2262F50 22.6K OHM +-1% 1/4W
PA16 R482 ns
p
00MGM11412100 CHIP RES. 121 OHM +-1% 1/4W
PA16 R483 ns
p
00MGM11412100 CHIP RES. 121 OHM +-1% 1/4W
PA16 R484 ns
p
00MGM114681G0 CHIP RES. 68.1 OHM +-1% 1/4W
PA16 R485 ns
p
00MGM11433220 CHIP RES. 33.2K OHM +-1% 1/4W
PA16 R486 ns
p
00MGM11456200 CHIP RES. 562 OHM +-1% 1/4W
PA16 R487 ns
p
00MGM11456200 CHIP RES. 562 OHM +-1% 1/4W
PA16 R488 00MNI05101110 00MNI05101110 CHIP RES. 100 OHM +-5% 1/10W
PA16 R489 ns
p
00MGM11446420 CHIP RES. 46.4K OHM +-1% 1/4W
PA16 R491 ns
p
00MGM11410000 CHIP RES. 100 OHM +-1% 1/4W
PA16 R492 ns
p
00MGM11446400 CHIP RES. 464 OHM +-1% 1/4W
PA16 R493 ns
p
00MGM11417800 CHIP RES. 178 OHM +-1% 1/4W
PA16 R494 ns
p
00MGM11446400 CHIP RES. 464 OHM +-1% 1/4W
PA16 R495 ns
p
00MGM11417800 CHIP RES. 178 OHM +-1% 1/4W
PA16 R497 ns
p
00MGM114100G0 CHIP RES. 10 OHM +-1% 1/4W
PA16 R498 ns
p
00MGM114100G0 CHIP RES. 10 OHM +-1% 1/4W
PA16 R499 ns
p
00MGM114464G0 CHIP RES. 46.4 OHM +-1% 1/4W
PA16 R500 ns
p
00MGM11410030 CHIP RES. 100K OHM +-1% 1/4W
PA16 R601 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PA16 R602 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PA16 R603 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PA16 R604 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PA16 R605 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +-5% 1/16W
PA16 R606 ns
p
00MNN05224610 CHIP RES. 220K OHM +-5% 1/16W
PA16 R691 F N ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16W
PA16 R692
/
K1G ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16W
PA16 R692
/
N1G ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16W
PA16 R693
/
U1G ns
p
00MNN05000610 CHIP RES. 0 OHM +-5% 1/16W
PA16 R841 ns
p
00MGM11410000 CHIP RES. 100 OHM +-1% 1/4W
PA16 R851 ns
p
00MGM11410000 CHIP RES. 100 OHM +-1% 1/4W
PA16 R852 ns
p
00MGM11410000 CHIP RES. 100 OHM +-1% 1/4W
PA16 R853 ns
p
00MGM11433210 CHIP RES. 3.32K OHM +-1% 1/4W
PA16 R854 ns
p
00MGM11433210 CHIP RES. 3.32K OHM +-1% 1/4W
PA16 R855 ns
p
00MGM11427410 CHIP RES. 2.74K OHM +-1% 1/4W
PA16 R856 ns
p
00MGM11427410 CHIP RES. 2.74K OHM +-1% 1/4W
PA16 R857 ns
p
00MGM11433210 CHIP RES. 3.32K OHM +-1% 1/4W
PA16 R858 ns
p
00MGM11433210 CHIP RES. 3.32K OHM +-1% 1/4W
PA16 RN09 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PA16 RN10 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PA16 RN11 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PA16 RN12 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PA16 RN13 ns
p
00MNN05332610 CHIP RES. 3.3K OHM +-5% 1/16W
PA16 RN14 ns
p
00MNN05224610 CHIP RES. 220K OHM +-5% 1/16W
PA16 RN15 ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16W
PA16 RN16 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PA16 RN17 ns
p
00MNN05104610 CHIP RES. 100K OHM +-5% 1/16W
PA16 X101 00MJX67002270 00MJX67002270 X'TAL 67.7376MHZ UM-5
(
ZT23522
)
PA16 X102 00MZK27AK0100 00MZK27AK0100 UNIT KIT DSB321SD
(
ZT20231
)
TCXO 33.8688MHZ
PA16 X103 00MZK27AK0110 00MZK27AK0110 UNIT KIT DSV321SV
(
ZT19595
)
VCXO 67.7376MHZ
POWER PWB PP16
(
00MWG27AK101-
)
PP16 C802 ns
p
00MOA68801620 ELECT CAP. 6800 UF 16V RA2 TYPE
PP16 C803 ns
p
00MOA68801620 ELECT CAP. 6800 UF 16V RA2 TYPE
