Marantz SA-7S1f - Page 40

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-54
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PP16 C804 ns
p
00MOA22702520 ELECT CAP. 220 UF M 25V RA-2
PP16 C805 ns
p
00MOA33800620 ELECT CAP. 3300UF M 6.3V RA-2
PP16 C806 ns
p
00MOA68801620 ELECT CAP. 6800 UF 16V RA2 TYPE
PP16 C811 ns
p
00MOA47802520 ELECT CAP. 4700UF/25V RA-2
PP16 C813 ns
p
00MOA47801620 ELECT CAP. 4700UF 16V RA2
PP16 C814 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE
(
220UF 16V
)
PP16 C815 ns
p
00MOA22705020 ELECT CAP. 220 UF M 50V RA-2
PP16 CE04 ns
p
00MOA107025Z0 ELECT CAP. ROS-25V 101M-H4#PE
(
100UF 25V
)
PP16 CN01 ns
p
00MOA10703520 ELECT CAP. 100 UF M 35V RA-2
PP16 CN02 ns
p
00MOA10510020 ELECT CAP. 1UF100V RA-2TYPE
PP16 CN03 ns
p
00MOA47505020 ELECT CAP. 4.7 UF M 50V RA-2
PP16 CN04 ns
p
00MOA22803520 ELECT CAP. 2200UF M 35V RA-2
PP16 CT09 ns
p
00MOA107025Z0 ELECT CAP. ROS-25V 101M-H4#PE
(
100UF 25V
)
PP16 D801 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D802 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D803 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D804 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D805 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D806 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D807 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D808 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D811 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D812 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D813 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 D814 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN01 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN02 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN03 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN04 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN05 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN06 00MHD31001000 00MHD31001000 ZENER DIODE 10V ZENER EQUIVALENT
PP16 DN07 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PP16 DN11 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN12 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN13 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN14 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100V
PP16 DN15 00MHD31801000 00MHD31801000 ZENER DIODE 18V ZENER EQUIVALENT
PP16 DN16 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1A
PP16 F801 0520100130040 0520100130040 FUSE # 021801.6MXP T1.6A L 250V
PP16 F811 0520100110080 0520100110080 FUSE # 0218001.MXP T1A L 250V
PP16 F821 0520100110080 0520100110080 FUSE # 0218001.MXP T1A L 250V
PP16 F841 0520100110080 0520100110080 FUSE # 0218001.MXP T1A L 250V
PP16 F851 0520100110080 0520100110080 FUSE # 0218001.MXP T1A L 250V
PP16 F853 0520100110080 0520100110080 FUSE # 0218001.MXP T1A L 250V
PP16 FH01 F N ns
p
0520100150000 FUSE # S506-3.15A
PP16 FH01
/
K1G ns
p
0520100130040 FUSE # 021801.6MXP T1.6A L 250V
PP16 FH01
/
N1G 0520100130040 0520100130040 FUSE # 021801.6MXP T1.6A L 250V
PP16 FH01
/
U1G ns
p
0520100150000 FUSE # S506-3.15A
PP16 GH01 00MDF77103500 00MDF77103500 FILM CAP. ! 0.01UF M 250V AC
PP16 J804 00MYJ10005000 00MYJ10005000 JACK 10R-FJ
(
10P RECEPTACLE
)
PP16 JE01 00MYT02011760 00MYT02011760 TERMINAL P2201-K 1P BNC
PP16 JT02 00MYJ15000220 00MYJ15000220 OPT. CONN. TOTX179L TOSLINK TRANSCEIVER
PP16 LE01 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PP16 LT01 00MTP41042030 00MTP41042030 TRANSF. PULSE TRNSF.
(
TPS247MN-0386AN
)
PP16 LT02 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PP16 LT03 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PP16 LT04 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
PP16 Q801 00MHC3190532F 00MHC3190532F IC ! PQ05RD21 5V 2A
PP16 Q811 00MHC3891209F 00MHC3891209F IC ! NJM7812FA +12V
PP16 Q812 00MHC3890809F 00MHC3890809F IC ! NJM7808FA +8V 1A
PP16 QE01 00MHC700400U0 00MHC700400U0 IC MC74HCU04AN
PP16 QN01 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PP16 QN02 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PP16 QN03 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
PP16 QN04 00MHT41415100 00MHT41415100 TRS. ! TRANSISTOR 2SD1415
PP16 QT01 00MHC700400U0 00MHC700400U0 IC MC74HCU04AN
PP16 R891 F N ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
