NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-55
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PP16 R891
/
U1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
PP16 R892 F N ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
PP16 R892
/
U1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
PP16 R893
/
K1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
PP16 R893
/
N1G ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
PP16 RE01 ns
p
00MGD05750160 RES. 75 OHM +-5% 1/6W
PP16 RE02 ns
p
00MGD05102160 RES. 1K OHM +-5% 1/6W
PP16 RE03 ns
p
00MGD05222160 RES. 2.2K OHM +-5% 1/6W
PP16 RE04 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
PP16 RE05 ns
p
00MGD05470160 RES. 47 OHM +-5% 1/6W
PP16 RE06 ns
p
00MGD05104160 RES. 100K OHM +-5% 1/6W
PP16 RN01 ns
p
00MGD05122160 RES. 1.2K OHM +-5% 1/6W
PP16 RN02 ns
p
00MGD05153160 RES. 15K OHM +-5% 1/6W
PP16 RN03 ns
p
00MGD05225160 RES. 2.2M OHM +-5% 1/6W
PP16 RN04 ns
p
00MGD05473160 RES. 47K OHM +-5% 1/6W
PP16 RN05 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PP16 RN06 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6W
PP16 RN08 ns
p
00MGD05272160 RES. 2.7K OHM +-5% 1/6W
PP16 RT01 ns
p
00MGD05122160 RES. 1.2K OHM +-5% 1/6W
PP16 RT02 ns
p
00MGD05104160 RES. 100K OHM +-5% 1/6W
PP16 RT03 ns
p
00MGD05220160 RES. 22 OHM +-5% 1/6W
PP16 RT04 ns
p
00MGD05330160 RES. 33 OHM +-5% 1/6W
PP16 RT05 ns
p
00MGD05750160 RES. 75 OHM +-5% 1/6W
PP16 RT07 ns
p
00MGD05101160 RES. 100 OHM +-5% 1/6W
PP16 SH01 00MSP01011990 00MSP01011990 PUSH SW ! SDDLD1 POWER SWITCH TV-3
FRONT1 PWB PY16
(
00MWG27AK102-
)
PY16 CY02 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY03 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY04 00MEY47600620 00MEY47600620 ELECT CAP. 47UF/6.3V
PY16 CY05 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY06 ns
p
00MDK96471300 CER. CAP. 470PF
(
GR39
)
PY16 CY07 00MEY22505020 00MEY22505020 ELECT CAP. 2.2UF/ 50V
PY16 CY08 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY09 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY10 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY11 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY12 ns
p
00MDK98474200 CER. CAP. GRM39F474Z16PT 0.47UF F 16V
PY16 CY13 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY14 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PY16 CY15 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY16 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR36
PY16 CY17 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR36
PY16 CY18 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR36
PY16 CY19 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10% B 50V GR36
PY16 CY20 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY21 00MEY47600620 00MEY47600620 ELECT CAP. 47UF/6.3V
PY16 CY22 ns
p
00MDK96471300 CER. CAP. 470PF
(
GR39
)
PY16 CY31 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY32 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY61 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PY16 CY62 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY63 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY64 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY65 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY67 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 CY68 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY16 DY11 00MHZ30751000 00MHZ30751000 CHIP DIODE 7.5V ZENER MA8075-M,UDPS7.5B
PY16 DY27 00MHI10046080 00MHI10046080 L.E.D. BLUE LED SELU2E10C-P-E/F
PY16 DY28 00MHI10046080 00MHI10046080 L.E.D. BLUE LED SELU2E10C-P-E/F
PY16 LY01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PY16 LY02 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PY16 LY03 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PY16 QY01 00MHC98203090 00MHC98203090 IC NJU7222U33-TE1 3.3V REG.
PY16 QY02 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PY16 QY07 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PY16 QY08 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PY16 QY09 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
