Marantz SR-14 - Page 43

69
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P104- FM/AM TUNER
TONE VOL. CIRCUIT BOARD
P104-CAPACITORS
C201 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C202 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C203 4822 122 40306 CER. 0.047µF +80%-20% Z 50V DK18473310
C204 4822 122 40306 CER. 0.047µF +80%-20% Z 50V DK18473310
C205 4822 124 42182 ELECT. 3.3µF M 50V OA33505020
C206 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C207 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C208 4822 122 40306 CER. 0.047µF +80%-20% Z 50V DK18473310
C209 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C210 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C211 4822 124 40763 ELECT. 2.2µF M 50V RA-2 OA22505020
C212 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
C213 4822 124 22273 ELECT. 0.47µF M 50V RA-2 OA47405020
C214 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C215 4822 122 40306 CER. 0.047µF +80%-20% Z 50V DK18473310
C216 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C218 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C219 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C223 4822 122 40586 CER. 10000pF ±20% DA17103110
C225 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C226 4822 122 40586 CER. 10000pF ±20% DA17103110
C233 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C234 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C235 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C236 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C237 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C303 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C304 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C305 /K,/N,/S 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C305 /U JUMPER 75060501P0
C306 /K,/N,/S 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C306 /U JUMPER 75060501P0
C311 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C312 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
C313 /K,/N,/S 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C314 /K,/N,/S 4822 124 41539 ELECT. 47µF M 16V RA-2 OA47601620
C315 /K,/N,/S 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C316 /K,/N,/S 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C351 /N,/S 4822 122 40586 CER. 10000pF ±20% DA17103110
C352 /N,/S 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C356 /N,/S 4822 126 11553 CER. 15pF ±5% 50V DA15150120
C357 /N,/S 4822 126 11553 CER. 15pF ±5% 50V DA15150120
C358 /N,/S 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C361
/N,/S 4822 126 10364 CER. 100pF ±10% DA16101110
C364
C365 /N,/S 4822 124 41539 ELECT. 47µF M 16V OA47601620
C366 /N,/S 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
C373 /N,/S 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C374 /N,/S 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
C501 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
C502 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
C503 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C504 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C505 4822 124 40763 ELECT. 2.2µF M 50V OA22505020
C507 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C508 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
C511 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CA01 4822 125 50384 TRIM. 20pF VCT51E CT12000200
CA02 4822 122 40306 CER. 0.047µF +80%-20% Z 50V DK18473310
CA03 4822 122 31823 CER. 15pF ±5% CH 50V BLK DD15150300
CA04 4822 121 42466 FILM 390pF 100V ECQ-P DF15391550
CA05 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CA06 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CA07 /N 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CA08 /N 4822 125 50384 TRIM. 20pF VCT51E CT12000200
CA09 /N 4822 122 31823 CER. 15pF ±5% CH 50V BLK DD15150300
CA11 /N 4822 122 31349 CER. 68pF ±5% CH 50V BLK DD15680300
CA12 /N 4822 122 10367 CER. 150pF ±5% CH 50V BLK DD15151300
CA13 /N 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CA14 /N 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CA18 4822 124 80067 ELECT. 4.7µF M 50V RA-2 OA47505020
CC07 5322 124 21731 ELECT. 10µF 50V RA-2 OA10605020
CC08 5322 124 21731 ELECT. 10µF 50V RA-2 OA10605020
CC18 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC23
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC26
CC27 /N,/S 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CC28 /N,/S 4822 122 31205 CER. 47pF ±5% CH 50V BLK DD15470300
CC31 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CC32 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CC33 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CC34 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CC35 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC36 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC39
4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC42
CC43 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CC44 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CC47 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC48 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC51 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC52 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC55 4822 122 31237 CER. 82pF ±5% 50V DD15820300
CC56 4822 122 31237 CER. 82pF ±5% 50V DD15820300
CC57 4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CC58 4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CC59 4822 124 90354 ELECT. 100µF 16V OA10701620
CC60 4822 124 90354 ELECT. 100µF 16V OA10701620
CC61 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC62 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CC71 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC72 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CC77 4822 124 41796 ELECT. 22µF M 16V OA22601620
CC78 4822 124 41796 ELECT. 22µF M 16V OA22601620
CC79 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CC80 4822 122 30043 CER. 10pF D CH 50 DK18103310
CC81 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CC82 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CF01 4822 124 41796 ELECT. 22µF M 16V OA22601620
CF02 4822 124 41796 ELECT. 22µF M 16V OA22601620
CF03 4822 122 31237 CER. 82pF ±5% 50V DD15820300
CF04 4822 122 31237 CER. 82pF ±5% 50V DD15820300
CF05 5322 124 21731 ELECT. 10µF 50V OA10605020
CF06 5322 124 21731 ELECT. 10µF 50V OA10605020
CF15 5322 124 21731 ELECT. 10µF 50V OA10605020
CF16 5322 124 21731 ELECT. 10µF 50V OA10605020
CF17 4822 124 41796 ELECT. 22µF M 16V OA22601620
CF18 4822 124 41796 ELECT. 22µF M 16V OA22601620
CF19 4822 126 10364 CER. 100pF ±10% DA16101110
CF20 4822 126 10364 CER. 100pF ±10% DA16101110
CF21 5322 124 21731 ELECT. 10µF 50V OA10605020
CF22 5322 124 21731 ELECT. 10µF 50V OA10605020
CF31 5322 124 21731 ELECT. 10µF 50V OA10605020
CF32 5322 124 21731 ELECT. 10µF 50V OA10605020
CF33 4822 124 90354 ELECT. 100µF 16V OA10701620
CF34 4822 124 90354 ELECT. 100µF 16V OA10701620
CF35 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CF36 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CF37 4822 124 90354 ELECT. 100µF 16V OA10701620
