Marantz SR-14 - Page 44

70
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CF38 4822 124 90354 ELECT. 100µF 16V OA10701620
CF39 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CF40 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CG51 ELECT. 22µF M 25V ARS OA22602540
CG52 ELECT. 22µF M 25V ARS OA22602540
CG53 ELECT. 22µF M 25V ARS OA22602540
CG54 5322 124 21731 ELECT. 10µF 50V OA10605020
CG55 ELECT. 22µF M 25V ARS OA22602540
CG56 ELECT. 22µF M 25V ARS OA22602540
CG57 CER. 0.1µF +80%-20% 50V DC DD38104010
CG59 4822 124 90354 ELECT. 100µF 16V OA10701620
CG60 4822 124 90354 ELECT. 100µF 16V OA10701620
CG61 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CG62 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CG63
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CG66
CG67 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CG68 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CG69 4822 124 90354 ELECT. 100µF M 16V OA10701620
CG70 4822 124 90354 ELECT. 100µF M 16V OA10701620
CG71 4822 122 40586 CER. 0.01UF DA17103110
CG72 4822 122 40586 CER. 0.01 UF DA17103110
CV01 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CV02 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
P104-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C220 C222 C227[U]
C317[/K,/N,/S] C318[/K,/N,/S]
C353[/N,/S] C354[/N,/S] C367
C368 C371 C372 C510 CC83
CC89-CC92[/N,/S] CV03
CV05-CV07
PLASTIC FILM CAPACITOR
±5% 50V : C217 C301 C302
C309[/K] C310[/K] CC01-CC04
CC14-C17 CC75 CC76
CF07-CF14 CF23-CF30
P104-RESISTORS
R101 /U 10kΩ ±5% 1/2W GG05103120
R201 /U JUMPER 75060501P0
R207 4822 050 21801 180Ω ±5% 1/4W GG05181140
R211 /K,/N,/S 4822 100 11352 TRIM. 22kΩ RH0638CJ4R RA02230780
R211 /U 4822 100 11351 TRIM. 10kΩ RH0638CS3R RA01030780
R212 4822 100 11351 TRIM. 10kΩ RH0638CS3R RA01030780
R217 4822 050 21801 180Ω ±5% 1/4W GG05181140
R301
/U JUMPER 75060501P0
R304
R313 /K,/N,/S 4822 116 83929 220Ω ±5% 1/4W GG05221140
R314 /K,/N,/S 4822 116 83929 220Ω ±5% 1/4W GG05221140
R356 /N,/S 4822 053 10471 470Ω ±5% 1W GA05471010
R512 4822 053 10271 270Ω ±5% 1W GA05271010
RA11 4822 100 11351 TRIM. 10kΩ RH0638CJ4R RA01030780
RC01 JUMPER 75060501P0
RC02 JUMPER 75060501P0
RC16 JUMPER 75060501P0
RC19 JUMPER 75060501P0
RC51 JUMPER 75060501P0
RC52 JUMPER 75060501P0
RC91 JUMPER 75061251P0
RC92 JUMPER 75061251P0
RF37 JUMPER 75060501P0
RF38 JUMPER 75060501P0
RG55 JUMPER 75060501P0
RG56 JUMPER 75060501P0
RG59 JUMPER 75060501P0
RG60 JUMPER 75060501P0
P104-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R201[/K,/N,/S]
R202-R206 R208-R210
R213-R216 R220 R221[/N,/S]
R301-R304[/N,/S] R307-R310
R315 R316 R352-R354[/N,/S]
R357[/N,/S] R502 R504-R507
R508[/N,/S] R509-R511 R513
R515 RA01 RA02 RA03[/N]
RC04[/N] RC06-RA10[/N]
RC03-RC18 RC20-RC33
RC35-RC42 RC53-RC62
RC71-RC82 RF01-RF36
RF39-RF46 RF48 RF49
RG51-RG54 RV01-RV14
P104-SEMICONDUCTORS
D201 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D202 4822 130 80319 ZENER DIODE 9.1V
RD9.1JB2 MTZJ9.1C
HD30911000
D351 /N,/S 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
D501 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
D502 /N 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D503 /N 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
D516 4822 130 32362 DIODE 1S133 HD20002000
DA01 4822 125 50416 VARICAP SVC342-L HD40009030
DA02 /K,/N,/S JUMPER 75060501P0
DA02 /U JUMPER 75060501P0
DA03 /N 4822 125 50416 VARICAP SVC342-L HD40009030
DA04 /N 4822 130 33697 DIODE 1SS135 HD20017210
DA05 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DA06 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF02 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DF03 9965 000 01363 DIODE 1SS201 HE10201050
DF04 9965 000 01363 DIODE 1SS201 HE10201050
DV05 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DV06
4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DV12
DV13 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
Q201 9965 000 01369 IC LA1837 FM AM IF MPX HC10384030
Q202 4822 130 62294 TRS. 2SC1809S P 150MW
500MHz
HT318091P0
Q203 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q204 4822 130 42594 DIG.TRS.
DTC144ES UN4213 47k 47k
BA20002000
