Marantz SR-14 - Page 45

71
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q209 /N,/S 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC
HT30001000
Q301 /K,/N,/S 4822 209 83631 IC NJM4558D-D HC10008090
Q351 /N,/S 4822 209 16175 IC LC72720L RDS DECODER HC10385030
Q352 /N,/S 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
Q353 /N,/S 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
Q501 9965 000 01370 IC LC72130 HC10394030
QA01 /N 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QA02 /N 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QA03 /N 4822 130 61892 TRS. 2SD2144S U OR V HT421442A0
QA04 /N 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QA05 /N 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QA06 /N 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QC01
4822 209 73064 IC NJM2068DD HC10053090
QC05
QC06 4822 209 32554 IC LC78213 HC10310030
QC07 4822 209 62784 IC TC9215P HC10262050
QC51 4822 209 31153 IC NJM2114D OP-AMP HC10111090
QC71 4822 209 31153 IC NJM2114D OP-AMP HC10111090
QC72 4822 209 62784 IC TC9215P ANALOGUE SW HC10262050
QF01 4822 209 73064 IC NJM2068DD HC10053090
QF02 9965 000 01365 IC TC9184AP ELE.TONE HC10444050
QF03 4822 209 73064 IC NJM2068DD HC10053090
QF04 9965 000 01365 IC TC9184AP ELE.TONE HC10444050
QG51 9965 000 01373 IC TC9459F ELE-VOL HC10449050
QG52 9965 000 01373 IC TC9459F ELE-VOL HC10449050
QG53 9965 000 01373 IC TC9459F ELE-VOL HC10449050
QG54 4822 209 91175 IC OP-AMP NJM2113M HC10175090
QG55 4822 209 91175 IC OP-AMP NJM2114M HC10175090
QV01 4822 209 90532 IC NJU3713D HC10161090
QV02
4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QV05
QV06 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QV07
4822 130 43818 TRS. 2SC2878 A OR B RANK HT328782A0
QV12
P104-MISCELLANEOUS
A101 9965 000 01368 VHF TUNER TFFJ4E AV00903010
F201 /K,/N,/S 4822 242 70665 CER. FILTER SFE10.7MS3-A FF11070620
F201 /U 4822 242 70911 CER. FILTER SFF10.7MA8-A FF11070610
F202 4822 242 70665 CER. FILTER SFE10.7MS3-A FF11070620
FA01 CER. FILTER SFZ450JL3 451K FF10045410
J101 4822 290 81632 TERMINAL YKD31-0215A
FM AM ANT PAL
YT03030020
JC05 9965 000 01315 TERMINAL 2P DIRECT IN
GLD BL BL CNT.SWF
YT02021550
JC06 9965 000 01316 TERMINAL YKC21-3953
GLD W R SURR.IN L R
YT02021500
L201 4822 157 63904 I.F.T. COIL FM DET
M292BEAS-5968Z
LI70376010
L301 4822 157 71731 M.P.X. COIL
LPF-V10-A1 19/38KHz
LS10293020
L302 4822 157 71731 M.P.X. COIL
LPF-V10-A1 19/38KHz
LS10293020
L350
/N,/S 4822 157 62911 CHOKE COIL 3.3µH LC13323800
L356 LAL02TA3R3JH
L359 /N,/S 4822 157 62911 CHOKE COIL 3.3µH
LAL02TA3R3JH
LC13323800
L501
4822 157 70813 CHOKE COIL 47µH LC14733800
L504 LAL02TA470J
LA01 4822 157 63084 MW ANT COIL 280µH LA10295170
LA02 4822 157 70779 OSC. COIL MW OSC C01L LO70013010
LA03 /N 4822 157 52714 ANT COIL LW ANT COIL LA10295160
LA04 /N 4822 157 70781 OSC. COIL LW OSC COIL LO70013020
LA05 4822 157 53589 CHOKE COIL 39MH J LC23960710
LA06 4822 148 81095 I.F.T. COIL AM IFT K7-H5
FOR SFP450D
LI70033510
S301 /K SLIDE SWITCH SSSS92 SS02021470
X351 /N,/S 4822 242 10857 CRYSTAL 4.332MHz AT-49 JX04003260
X501 4822 242 72333 CRYSTAL AD0618CTB 7.2MHz JX07001260
P604- AC-3 DTS & THX
DECODE CIRCUIT BOARD
P604-CAPACITORS
C601 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C602 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C603 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C604 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C605 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C606 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C607 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C608 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
C609 4822 122 33761 CER. CHIP 22pF ±5% CG 50V DD95220300
C610 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C611 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C612 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C613 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C614 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C615 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C616 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
C617 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C618 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C619 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C620 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C621 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C622 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C623 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C624 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C625 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C651 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C652 4822 126 11703 CER. CHIP 0.01µF +80%-20% DK98103300
C653 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C654 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C655 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C656 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C657 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C658
4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C662
C663 4822 126 13396 CER. CHIP 0.047µF ±10% 16V DK96473200
C664 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C666 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C667 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C668 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C669 4822 126 14417 CER. CHIP 0.01µF B 50V DK96103300
C670 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C680 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C691 4822 126 14417 CER. CHIP 0.01µF B 50V DK96103300
C692 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C693 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C694 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C695 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
C696 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
