Marantz SR-14 - Page 49

75
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
DE01 4822 130 10683 CHIP DIODE KV1851-TL00 HZ40003420
DR01 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DR02 4822 130 81324 CHIP DIODE 1SS302 HZ20018050
DR03 4822 130 80522 CHIP DIODE 1SS300 DAP202U HZ21006000
Q601 9965 000 01321 IC YSS912
DTS AC-3 DECODER
HC10014640
Q602 9965 000 01322 IC TC7WT241FU HC007405K0
Q603 9965 000 01323 IC TC7WT126FU HC007305K0
Q604 9965 000 01324 IC 1M SRAM 8X128K 15NS HC10088000
Q605 9965 000 01326 IC TCW32FU OR *2 HC10419050
Q651 4822 209 17013 IC ZR38600
AC-3 THX5.1 DECODER
HC10051990
Q652 9965 000 01338 IC TC7SET04F HC007205K0
Q691 9965 000 01339 MICROPROCESSOR SURR.
FOR THX µPD78018FGAB8
HU300JN50F
Q692 9965 000 01323 IC TC7WT126FU HC007305K0
Q693 4822 209 32921 IC S-80745AN HC10048530
Q694 4822 209 12845 IC S-80730SN-DT-X RESET HC10054530
QD01 9965 000 01319 IC AD1855 DAC 24BIT 96KHz HC10013840
QD02 9965 000 01319 IC AD1855 DAC 24BIT 96KHz HC10013840
QD03 9965 000 01319 IC AD1855 DAC 24BIT 96KHz HC10013840
QD41 9965 000 01319 IC AD1855 DAC 24BIT 96KHz HC10013840
QD42 9965 000 01319 IC AD1855 DAC 24BIT 96KHz HC10013840
QD43 4822 209 17526 IC TC160G11AU-1305 :
312020050070
HC10438050
QD44 4822 209 17526 IC TC160G11AU-1305 :
312020050070
HC10438050
QE01
4822 130 60669 CHIP TRS. 2SC4081 Q OR R HX300012A0
QE03 2SC4116 Y OR GR
QE04 4822 209 14876 IC MC14577C SOP TAPING HC10065170
QE05
4822 130 10698 CHIP TRS. 2SA1586 Y OR GR HX100012A0
QE07 2SA1576A Q OR R
QE08 4822 209 83357 IC NJM4560M HC10029090
QE09 4822 209 17162 IC PM4007A
AC-3 RF DEMODULATOR
HC10016660
QE10 4822 209 14864 IC 8X32K SRAM <35NS HC10076000
QH01 4822 209 91175 IC NJM2114M OP AMP HC10175090
QH02 4822 209 91175 IC NJM2114M OP AMP HC10175090
QH03 4822 209 91175 IC NJM2114M OP AMP HC10175090
QH04 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QH05 4822 130 43818 TRS. 2SC2878 A B HT328782A0
QH06 4822 130 43818 TRS. 2SC2878 A B HT328782A0
QH51 4822 209 91175 IC NJM2114M OP AMP HC10175090
QH52 4822 209 91175 IC NJM2114M OP AMP HC10175090
QH53 4822 209 91175 IC NJM2114M OP AMP HC10175090
QJ01 4822 209 91175 IC NJM2114M OP AMP HC10175090
QJ02 4822 209 91175 IC NJM2114M OP AMP HC10175090
QJ51 4822 209 91175 IC NJM2114M OP AMP HC10175090
QJ71 4822 209 91175 IC NJM2114M OP AMP HC10175090
QK01 9965 000 01317 IC CS5394 2CH.ADC 24BIT HC10003880
QK03
4822 209 91175 IC NJM2114M OP AMP HC10175090
QK06
QR01 9965 000 01341 IC CS8414 SPDIF RECEIVER HC10004880
QR02 9965 000 01342 IC TC74HC151AF HC715100Z0
QR03 9965 000 01342 IC TC74HC151AF HC715100Z0
QR04 4822 209 30426 IC CMOS 74HC00 HC700000Z0
QR05 4822 209 30426 IC CMOS 74HC00 HC700000Z0
QR06 4822 209 32879 IC TC74HC157A HC715705Z0
QR07 4822 209 31568 IC CMOS 74HCU04 HC700400Z0
QR08 4822 209 90909 IC TC7W74FU D-F F HC10400050
P604-MISCELLANEOUS
JE01 4822 267 10603 TERMINAL YKC21-3707 YT02011030
JR01 9965 000 01340 TERMINAL RCA 2P AU BL YT02021540
JR02 4822 218 11487 OPT. CONNECTOR GP1F32R
OPTICAL RECEIVER
YJ15000150
JR03 4822 218 11487 OPT. CONNECTOR GP1F32R
OPTICAL RECEIVER
YJ15000150
JR04 4822 267 31369 OPT. CONNECTOR GP1F32T
OPTICAL OUTPUT
YJ15000090
JR05 4822 290 81638 TERMINAL 14X14 RA 1L1P BL YT02010790
L601 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L602 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L651 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
L691
4822 157 10884 EMI FILTER BLM11A221S FN31000010
L697
LD01
4822 526 10584 FERRITE CORE FC90090010
LD03 ZBF503D-00TA
LD05
4822 526 10584 FERRITE CORE FC90090010
LD07 ZBF503D-00TA
LD41 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD42 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD45 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD46 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LD81
4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LD86
LE01 4822 157 70681 CHIP INDUCTANCE 68µH
NL322522-680K
LU12683010
LE02 4822 242 10582 L.C. FILTERR
SBP-4930 2.88MHz B.P.F
FF30288010
LE03 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LE04 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LH01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH51 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LH52 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LJ02 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LK01 4822 526 10584 FERRITE CORE
ZBF503D-00TA
FC90090010
LR01 4822 142 60422 PULSE TRANSF.
TPS247MN-0386AN
TP41042030
LR02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
X601 4822 242 10851 CRYSTAL 12.288MHz AT-49 JX12013260
X691 4822 242 81727 CERAMIC VIB.
CST10.0MTW-TF01 10.0MHz
FQ01005010
XE01 9965 000 01320 CRYSTAL 18.432MHz AT-49 JX18001260
P704- 3CH POWER-AMP.
CIRCUIT BOARD
P704-CAPACITORS
C701 4822 124 90058 ELECT. 47µF M 25V ARA OA47602550
C702 4822 124 90058 ELECT. 47µF M 25V ARA OA47602550
C703
FILM CAP 470pF ±5% 100V OF15471540
C706
C707 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
C708 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
